Eaton NetDirector B064-016-04-IPH Manual page 41

OSD Operation
Advanced Network Management Settings
SNMP Agent
The SNMP Agent allows you to configure Device Management
settings with an MIB browser using the MIB file obtained
from Eaton's technical support. The MIB file imports into the
MIB browser to configure the following Device Management
settings: Operating Mode; Mode; Network: IP Installer, Service
Ports, IPv4 / IPv6 Settings; ANMS - Event Destination: Log
Server, SNMP Trap.
To connect to the switch through an MIB browser, use the
instructions below to add an SNMP Agent to allow access from
the computer you will use to configure to the switch settings.
To add an SNMP Agent:
1. Check Enable.
2. Client Add. A window will appear.
3. Select the Version.
4. Enter a Community Name.
5. Key in NMS IP/Host Name. Enter the IP address of a
computer that will access the switch via a MIB browser.
6. Select the Access Type and click Save.
7. From a MIB browser, import the MIB file and then enter the
IP address of the switch.
41
