Table 4-6. Network Status LED (Continued)
For information about Module Status LED indications during power-up, refer to
Section 8.2.4 of the DeviceNet Specification (revision 2.0).

PASSIVE DISPLAY PANEL

The passive front panel and remote passive panel let you monitor power, current, or
voltage; receive error codes; and review several other conditions shown by the LEDs.

Display

At any time while the Pinnacle Plus+ supply is operating, you can press the DISPLAY
button to the left of the four-digit display to find the number of kilowatts, volts, or
amps being delivered or to display the frequency setting or the reverse time setting.
5702269-C
Page 57 of 204
If the LED is
Flashing Amber
Amber
I/O Communication and Control
the state indicated is
Connection Time-out,
Critical Link Failure
Critical Link Failure
Pinnacle™ Plus+ 10 kW
which means that
one or more I/O
connections are in the
timed-out state.
communication has
failed; that is, the unit has
detected an error that has
made it incapable of
communicating on the
network.
Note: If you have a dual
Pinnacle Plus+
unit, the causes of
this failure may be:
1) the two
DeviceNet cards
are not set to the
same Data Rate as
the network; or 2)
the two DeviceNet
cards have the
same Node
Address.
4-13
