Table 4-19. AE Bus Commands (Continued)
Command
31
out-of-set
point timer
32
ramp start
point
(percentage
of set point)
33
recipe type
34
over-voltage
timer
4-70
Page 114 of 204
®
Description
Enables or disables an out-of-set point timer
and specifies how long you want the power
supply to tolerate an out-of-set point condition
before shutting off output.
• To enable the timer, send a value (2 bytes)
between 1 and 9999 (0.1 to 999.9 s).
• To disable the timer, send a value of 0.
Read back this value with command 187.
Sets the ramp start point as a percentage of set
point when output is turned on. The range is 0
to 95%.
Send a 1 byte value of 0 to 95.
Read back this value with command 152.
Set the type of recipe. The default is "Timed."
Send 1 data byte:
• 1 = Timed
• 2 = Joule continuous
• 3 = Joule discrete
Read back with command 196.
Enables or disables an over-voltage timer and
specifies how long you want the power supply
to tolerate an over-voltage condition before
shutting off output.
• To enable the timer, send a value (2 bytes)
between 1 and 9999 (0.1 to 999.9 s)
• To disable the timer, send a value of 0
Read back with command 174.
I/O Communication and Control
Number CSR
of Codes or
Transmit Number of
Data Response
Bytes Bytes
2 CSR codes:
0,1,4,9
1 CSR codes:
0,1,4,9
1 CSR only
2 CSR codes:
0,1,4,9
