Table 3-5. Reverse Time as a Function of Voltage Limit (V-Limit)
3-12
Page 40 of 204
®
V-Limit Corresponding Reverse Time
(in Volts)
390 8.3 µs
395 8.2 µs
400 8.1 µs
405 8 µs
410 7.9 µs
415 7.8 µs
420 7.7 µs
425 7.6 µs
430 7.5 µs
435 7.4 µs
440 7.3 µs
445 7.3 µs
450 7.2 µs
455 7.1 µs
460 7 µs
465 6.9 µs
470 6.9 µs
475 6.8 µs
480 6.7 µs
485 6.7 µs
490 6.6 µs
495 6.5 µs
500 6.5 µs
505 6.4 µs
510 6.3 µs
515 6.3 µs
520 6.2 µs
525 6.1 µs
530 6.1 µs
535 6 µs
540 6 µs
545 5.9 µs
550 5.9 µs
Specifications 5702269-C
