Table 3-3. Electrical Specifications (Continued)

Maximum Allowable Reverse Time For a Given Frequency

Note: Frequency is limited to 150 kHz when the pulsing enabled mode is set to be
3-6
Page 34 of 204
®
Ignition Capability
Analog Interface Scaling
Output Polarities
Output Frequency
(self-run)
Reverse Time
Reverse Voltage
enabled always.
Voltage clamped to 1700 V at 50 mA maximum
Ignition cycle runs at 1400 V for 100 ms, then at
the user-selected maximum output voltage limit
for 900 ms.
Depending on the choice and configuration of
your User port, the analog input and output signals
will be either 0 to 5 V or 0 to 10 V full scale. If
your supply does not contain a User port that
emulates another supply, full scale for set point
input and readback output is as follows: for power,
0 to 10 kW; for current, 0 to 40 A; for voltage, 0 to
1500 V.
The UHF connector body is securely connected to
ground; therefore, the center connector may be
configured for positive or negative output.
5 kHz to 350 kHz, 5 kHz increments
Note: The PNCL PLUS+ self-run frequency has a
granularity of 50 ns. Therefore, the
maximum difference from set point-to-
actual is always <1% (never exceeding ±
2.6 kHz) maximum, with an average
difference across the frequency range of
<0.1%.
0.4 µs to 5.0 µs, 0.1 µs increments, up to a 45%
reverse duty cycle for a given frequency
See "Maximum Allowable Reverse Time For a
Given Frequency" on page 3-6 and "Frequency
and Reverse Time Settings" on page 6-3 for more
information.
Approximately 10% of the operating voltage
(voltage readback shown on the active front panel
interface).
Specifications 5702269-C
