MODULE STATUS LED

The MOD bi-color (amber/green) LED provides device status. It indicates whether
the device has power and is operating properly. The following table shows the LED's
various states and their meanings.

Table 4-5. MOD Status LED

For information on LED flash rates, refer to section 8.2.8 of the DeviceNet
Specification (revision 2.0).
For information about Module Status LED indications during power-up, refer to
Section 8.2.4 of the DeviceNet Specification (revision 2.0).
5702269-C
Page 55 of 204
If the LED is
Off
Green (steady)
Flashing Green
Amber
Flashing Amber/
Green
I/O Communication and Control
the state indicated is
No power
Operational
Standby
Unrecoverable Fault
Device Self-Testing
Pinnacle™ Plus+ 10 kW
which means that
the unit is not receiving
power.
the unit is operating
normally.
the unit needs
maintenance because the
configuration is missing,
incomplete, or incorrect.
the unit has experienced a
fault from which it
cannot recover; you may
need to replace the unit.
the unit is running self
diagnostics
4-11
