Advanced Energy Pinnacle Plus+ User Manual page 183

Table 7-3. Help Code Troubleshooting Table (Continued)
Help
Code
Number
H004
Continued
on next
page
5702269-C
Page 183 of 204
Help Code Problem Indicated
Message
You have attempted to set a
User Limit
power, voltage or current
Out of Range
limit to a value outside the
allowable range.
You have attempted to set a
Timer Out of
timer to a value outside the
Range
allowable range.
You have attempted to set
Arc Count Limit
the arc count limit to a value
Out of Range
outside the allowable range.
You have attempted to set
Arc Timer Out
the arc timer to a value
of Range
outside its allowable range.
You have attempted to set a
Arc Trip Level
trip level to a value outside
Out of Range
the allowable range.
You have attempted to set
Frequency Out
frequency to a value outside
of Range
the allowable range.
You have attempted to set
Reverse Time
reverse time to a value
Out of Range
outside the allowable range.
Troubleshooting and Global Customer Support
Pinnacle™ Plus+ 10 kW
Suggested Action
Retry setting the limit using
an acceptable value. See the
"Specifications" chapter for
more information.
Retry setting the timer using
an acceptable value. See the
"I/O Communication and
Control" chapter for more
information.
Retry setting the limit using
an acceptable value. See the
"I/O Communication and
Control" chapter for more
information.
Retry setting the timer using
an acceptable value. See the
"I/O Communication and
Control" chapter for more
information.
Retry setting the trip level
using an acceptable value.
See the "I/O Communication
and Control" chapter for
more information.
Retry setting the frequency
using an acceptable value.
See the "I/O Communication
and Control" chapter for
more information.
Retry setting the reverse time
using an acceptable value.
See the "I/O Communication
and Control" chapter for
more information.
7-7
