Error Code Troubleshooting Table

Table 7-4. Error Code Troubleshooting Table

5702269-C
Page 189 of 204
Error Code Message
E000
DSP Init Control
Fault
E001
Out of Setpoint
Timer Expired
E002
Bus Fault
E004
Heat Sink
Over-Temperature
Troubleshooting and Global Customer Support
Problem Indicated
The DSP failed to
respond to the processor.
The out-of-set point timer
has expired.
The DC bus has failed–
probably due to an AC
input power problem.
The unit is overheating.
Pinnacle™ Plus+ 10 kW
Suggested Action
Power the unit off and then
back on. If the error code
reappears, contact AE
Global Customer Support.
Increase the set point timer
value or disable the timer
by setting it equal to 0. If
the problem persists, check
your process parameters
for limiting factors. That is,
ensure that your load
impedance matches the
impedance of the Pinnacle
Plus+ unit.
Using all applicable safety
precautions, inspect your
AC input power source to
ensure that it is properly
connected and that the
specified voltage is being
applied to the Pinnacle
Plus+ unit. (See the
"Specifications" chapter
for AC input power
specifications.)
Inspect the unit's cooling
system and review cooling
specifications: ensure that
the input air temperature is
correct, that the Pinnacle
Plus+ unit's fans are
functioning properly, and
that your cabinet allows for
adequate ventilation for all
the units in the cabinet. For
more information, see the
"Installation" chapter.
7-13
