Table 4-19. AE Bus Commands (Continued)
Command
59
joule recipe
repetition
61
enable/
disable micro
arc handling
64
threshold
type
65
pulsing
enabled
mode
4-74
Page 118 of 204
®
Description
Send 2 data bytes (16-bit value). Valid input
for the joule recipe repetitions are 1 through
65535.
Note: This command is only valid when you
set the continuous joule recipe type.
Readback this value with command 233.
Enables or disables micro arc handling feature.
Hard arc handling is always enabled.
Send 1 data byte (8-bit value):
• 0 = Disable
• Non-zero = Enable
Note: Cycling power to the unit resets arc
handling mode to enabled.
Read this value with command 163.
Sets the joule mode counter threshold type.
Send one data byte (8-bit value):
• 0 = Power
• 1 = Voltage
• 2 = Current
Read back this setting with command 163.
Enables pulsing at the current threshold
(default setting) or always.
Note: Frequency is limited to 150 kHz when
the pulse mode is set to be enabled
always.
Send one data byte (8-bit value):
• 0 = Pulsing enabled at current threshold
• 1 = Pulsing enabled always
Read back this setting with command 163.
I/O Communication and Control
Number CSR
of Codes or
Transmit Number of
Data Response
Bytes Bytes
2 CSR only
1 CSR codes:
0,1
1 CSR codes:
0,1,2,4,9
1 CSR codes:
0,1,2,4,9
