Table 4-19. AE Bus Commands (Continued)
Command
155
request
control mode
156
request
active target
number
157
request target
life
158
request ramp
time
159
ramp time
remaining
5702269-C
Page 125 of 204
Description
Requests control mode; the returning packet
contains 1 data byte (8-bit value):
• 2 = Serial (Host) port
• 3 = Active control panel (Local)
• 4 = User port
This value is set with command 14.
Requests an indication of the active target; the
returning packet contains 1 data byte indicating
target 1, 2, 3, 4, 5, 6, 7, or 8.
This value is set with command 11.
Requests the amount of target life time
remaining for the target you specify.
Send 1 data byte indicating which target; the
returning packet contains 4 data bytes (32-bit
value) indicating the time remaining in
kilowatt-hours. Two decimal places are
implied. For example, a value of 100 indicates
1 kWh.
This value is set with command 12.
Requests ramp time. Returns a 2-byte value (16
bits) indicating a ramp time of 5 (50ms) to
60,000 (600.00 s).
Note: If your unit has 100 ms ramp feature
enabled, one decimal is implied. The
range is 0.5 s to 6000.0 s.
This value is set with command 16.
Requests how much ramp time is remaining.
Returning packet contains 2 data bytes
(16 bits), indicating how many 10 ms intervals
remain.
Note: If your unit has 100 ms ramp feature
enabled, the data indicates how many
100 ms intervals remain.
I/O Communication and Control
Pinnacle™ Plus+ 10 kW
Number
CSR
of
Codes or
Transmit
Number of
Data
Response
Bytes
Bytes
0
1
0
1
1
4
(May return
CSR code 4)
0
2
0
2
4-81
Ex. 1024 Page 125
