Table 3-5. Reverse Time as a Function of Voltage Limit (V-Limit)

Operating and Impedance Range Illustrations

The following graphs illustrate the output power operation range and output
impedance range for your Pinnacle Plus+ power supply.
5702269-C
Page 41 of 204
V-Limit Corresponding Reverse Time
(in Volts)
555 5.8 µs
560 5.8 µs
565 5.7 µs
570 5.7 µs
575 5.6 µs
580 5.6 µs
585 5.5 µs
590 5.5 µs
595 5.4 µs
600 5.4 µs
605 5.3 µs
610 5.3 µs
615 5.2 µs
620 5.2 µs
625 5.2 µs
630 5.1 µs
635 5.1 µs
640 5 µs
645 5 µs
650 5 µs
Specifications
Pinnacle™ Plus+ 10 kW
3-13
