Table 4-19. AE Bus Commands (Continued)
Command
163
request
config status
4-86
Page 130 of 204
®
Description
Requests the system configuration status; the
returning packet contains 4 data bytes.
1st status byte:
• 0 = Host program source
(0 = internal, 1 = external)
• 1 = Local program source
(0 = internal, 1 = external)
• 2 = Analog program source
(0 = internal, 1 = external)
• 3 = Unassigned
• 4 = Unassigned
• 5 = Unassigned
• 6 = Program source
(0 = internal, 1 = external)
• 7 = Target life status
(0 = inactive, 1 = active)
2nd status byte:
• 0 = Profibus Status Bit Definition
(0 = normal, 1 = Joule Recipe)
• 1 = Active control panel access
(0 = unlocked, 1 = locked)
• 2 = Joule mode (0 = disabled, 1 = enabled)
• 3 = Contactor status (0 = open, 1 = closed)
• 4 = Unassigned
• 5 = Ramp mode (0 = disabled,
1 = enabled)
• 6 = Unassigned
• 7 = Pulsing enabled (0 = disabled,
1 = enabled)
(Continued on next page)
I/O Communication and Control
Number CSR
of Codes or
Transmit Number of
Data Response
Bytes Bytes
0 4
