Table 3-1. Functional Specifications (Continued)

PHYSICAL SPECIFICATIONS

Table 3-2. Physical Specifications

5702269-C
Page 31 of 204
Cooling
Fault Conditions
Size
Weight
Output Connector
Output Power Cable
Input Power Connector
User Port Connector
Serial (Host) Port
Connector
Air-cooled
Several fault conditions will either cause the
Pinnacle Plus+ supply to shut off output or
prevent output from being turned on. These
conditions include open interlock loops, input
power failure, over-temperature, and user-
controlled timers.
133 mm (H) x 483 mm (W) x 639 mm (D),
including connectors
(5.22 in (H) x 19 in (W) x 25.18 in (D))
30 kg (66 lb)
Two terminal, multi-contact, pluggable connector
or UHF connector
For optimal performance, it is recommended that
you use an output power cable 3.05 m (10´) in
length—or shorter.
Note: The output power cable must not exceed 10
m (32.8´) or you may damage your power
supply.
Five terminal, DIN compression terminal block.
Maximum wire size #6AWG
Please reference the "I/O Communication and
Control" chapter.
Please reference the "I/O Communication and
Control" chapter.
Specifications
Pinnacle™ Plus+ 10 kW
3-3
