The AC line input connection is provided by means of a five terminal, DIN terminal
block on the rear panel. Labels on the input terminal shield and below each terminal
position on the rear panel show line (L3, L2, L1), neutral (N), and Protective Earth
(ground) connections.
Note: No neutral connection is required. However, if neutral is present, connect it to
To connect your system to the power supply, you need stranded wire of a gauge
consistent with your application and applicable requirements and the power input
specification.
To connect to the power supply's input power connector:

Connecting Output Power

5-8
Page 154 of 204
®
the N terminal.
This device must be operated in an overvoltage II category installation
only.
1. Strip approximately 60 to 70 mm of the insulation from the end of the power cord.
2. Separate the five wires and strip approximately 10 mm of the insulation from each
wire.
3. Ensure that the ground wire (the yellow and green wire) is approximately 7 mm
longer than the other wires.
4. Crimp on each lead a ferule of appropriate size.
5. Remove strain relief housing.
6. Slip the cable through the strain relief.
7. Connect each wire to the proper input terminal block according to the labels.
Replace the housing. Tighten strain relief.
RISK OF DEATH OR BODILY INJURY. Disconnect all sources of input
power before working on this unit or anything connected to it.
Installation
5702269-C
Ex. 1024 Page 154
