SETTING THE UNIT AS A SYNC PULSE TRANSMITTER OR
RECEIVER
SUPPLY → PULSE → TX/RX
Note: This feature is only available if your Pinnacle Plus+ unit was specifically
To set the unit as a Sync Pulse transmitter or receiver:
Note: One unit must be set to transmit; all other units must be set to receive.
If your unit is configured with a Sync Pulse port you may set up to six Pinnacle Plus+
units to operate in a Sync Pulse system. See the section titled "Master/Slave
Operation" near the end of chapter 5 of this manual for more information.

Selecting Constant Duty Cycle

SUPPLY → PULSE → DUTY_CYC
The constant duty cycle feature automatically updates the reverse time when you
change frequency, allowing you to maintain the same duty cycle that was present
before the change—within a limited frequency range.
Note: To change the duty cycle, change the reverse time.
To select the constant duty cycle feature:

Setting the Program Source

SUPPLY → PGM_SRC
The program source (PGM_SRC) feature specifies for each control mode the program
source for regulation mode and set point information. For each control mode, if the
program source is set to internal (INT), the Pinnacle Plus+ supply uses the information
for output regulation mode and set point that has been established through the active
front panel, the Pinnacle Remote Active Panel, or the standard serial port. If the
program source is set to external (EXT), the Pinnacle Plus+ supply uses the set point
and output regulation mode that has been established through the pins on the User
port.
To select the desired source and type:
5702269-C
Page 75 of 204
configured at the factory for Sync Pulse.
• Press SUPPLY → PULSE → TX/RX.
• Select TRANSMIT or RECEIVE.
1. Press SUPPLY → PULSE → DUTY_CYC.
2. Select YES to enable function.
1. Press SUPPLY → PGM_SRC.
I/O Communication and Control
Pinnacle™ Plus+ 10 kW
4-31
