S01AMNOMAT11
S01AMNOMATA0
S01AMNOMATT2
S01AMNOMATB?
S01AMNOMAT*1
S01AMNOMAT*0
S01AMNOMAT*1100
S01AMNOMAT*2
S01AMNOMAT*?
8.26. AMOFFAT -- Set Off Attenuation for the Specified
Automixer
This command sets the off attenuation (in dB) for the specified automixer. Setting this value to 18
would result in the microphone signals being attenuated by 18 dB when gated off. This value is set
independently for each of the automixers. The first argument of this command specifies the automixer
number (1-2) to adjust. The second argument specifies the off attenuation.
Even though this is a channel integer command, use of the wildcard for specifying the automixer
number is not supported.
This command is a channel integer command. See
on this type of command. The minimum and maximum values for this command are 1 and 100,
respectively.
Enable NOM attenuation on
output 1 .
Disable NOM attenuation on
output A.
Toggle NOM attenuation
status on output T (telephone
output) .
Query NOM attenuation status
of output B.
Enable NOM attenuation on all
outputs (1, A, B, T) .
Disable NOM attenuation on
all outputs (1, A, B, T) .
Enable NOM attenuation on
outputs 1 and A, and disable
NOM attenuation on outputs B
and T.
Toggle status of NOM
attenuation on all outputs.
Query NOM attenuation status
of all outputs.
S01AMNOMAT11
S01AMNOMATA0
S01AMNOMATTx , where x is either 0 or 1
depending on the current mute status of NOM
attenuation on the ouptut.
S01AMNOMATBx , where x is either 0 or 1
depending on the current NOM attenuation
status of the output.
S01AMNOMAT*1111
S01AMNOMAT*0000
S01AMNOMAT*1100
S01AMNOMAT*abcd , where each of the letters
(a, b, etc.) is either 0 or 1 depending of the
current status of NOM attenuation on the
corresponding output. If this command was
sent after the example above, then the status
message would be S01AMNOMAT*0011 .
S01AMNOMAT*abcd , where each of the letters
(a, b, etc.) is either 0 or 1 depending of the
current status of the NOM attenuation on the
corresponding output. If this command was
sent after the example above, then the status
message would be S01AMNOMAT*0011 .
Section 6.3
and
Section 6.2
for more information
