Peqob -- Set Bandwidth Parameter For Specified Parametric Eq Output Stage - Polycom Vortex EF2211 Programming Manual

S01PEQOA1,2,1,1250,40,-20,1,1
S01PEQOAB,1,?
8.122. PEQOB -- Set Bandwidth Parameter for Specified
Parametric EQ Output Stage
This command sets or queries the bandwidth parameter (in 1/100th octaves) for the parametric
equalizer (EQ) filters on output channels 1, A, B, and T . Each channel has five bands of parametric
EQ that can be independently controlled.
The minimum and maximum values for the bandwidth parameter are 5 and 200, respectively.
This command has the same format and restrictions as the
parameter, the bandwidth, is specified instead of all the parameters. See the
more information. To set the bandwidth parameter for an input parametric EQ filter, use the
command. To set all the parameters for an input parametric EQ filter, use the
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
Set the
parametric EQ on
output 1 , band 2
to the following
parameters: type
= parametric
filter, frequency
= 1250 Hz,
bandwidth = 40
1/100th octaves,
gain = -20 dB,
S01PEQOA1,2,1,1250,40,-20,1,1
enabled = yes,
slope = 1 dB per
octave. The
value of the
slope parameter
is irrelevant for
this type of filter,
we could have
set it to
anything.
S01PEQOAB,1,t,f,b,g,s,e , where
Query the the parameters t, f, b, g, s, and e
current
correspond to the current settings of the
parameter
type, frequency, bandwidth, gain, slope,
settings for the
and enabled parameters, respectively. If
parametric eq
this filter was set to the same parameters
filter on output B
as given in the above example, the status
, band 1.
message would be
S01PEQOAB,2,1,1250,40,-20,1,1 .
PEQOA
command except that only one
command for
PEQOA
command.
PEQIA
PEQIB
