Balanced Audio Connector

Description
3-pin Phoenix connector
This connector connects audio input and output to the VSX 8000.
Used With
VSX 8000
Top View
PIN #
1 Signal +
2 Signal - (return)
3 Shield/drain wire/ground
Drawings and part numbers are provided for reference only. Polycom claims no responsibility
or liability for the quality, performance, or reliability of cables based on these reference
drawings, other than cables provided by Polycom. Contact your Polycom distributor or
Polycom Custom/Vertical Products to order cables that meet the appropriate manufacturing
tolerances, quality, and performance parameters for your application.
Part Number
1515-20881-003
Phoenix part
number: 1939921
1
2
3
Cables
Length
—
2 - 27
