M3912D-500-72 - ITech IT-M3900D Series User Manual

Max. apparent
power
Max. input current
Max. efficiency
Power Factor
DC component
Current harmonics
Standard Interface
Command Re-
sponse Time
Parallel Number
Working
Temperature
Storage
Temperature
IP
Isolation DC to GND
Isolation AC to GND
Cooling
Dimension
（D*W*H）
Weight( net)
6.1.20 IT-M3912D-500-72
Parameter
Rated value
Frequency
*1: The ripple is got under three-phase AC input.
*2: At low voltage input, the set power will decrease. For more information,
please contact ITECH.
Voltage
Current
Power
Copyright © Itech Electronic Co., Ltd.
6.5kVA
12.5Aac
94.5%
0.99
≤0.2A
≤3%
Standard: USB/LAN/CAN/IO
Optional: GPIB/Analog&RS232
0.1ms
≤16
0～40℃
-10℃～70℃
IP20
800Vdc
3500Vdc
Air
744.22mm*459mm*56.81mm
15kg
IT-M3912D-500-72
0W～12000W
Technical Specification
50/60Hz
0～500V
0A～72A
157
