Compact design，power up to 6kW in 1U space, power up to12kW in 2U
space
•
Voltage range: 10-1500V
•
Current range:8A~1020A
•
Power range:1700W~12kW
•
Wide range of output design, one unit can be used as multiple power
supplies
•
Master/slave parallel connection, keep good performance while power
extension
•
CC/CV priority
•
Adjustable output impedance
•
Built-in function generator, support arbitrary-waveform generating
•
List function, up to 200 steps can be set
•
Support multiple working modes, adjustable rise and fall time The front panel
supports the insertion of USB storage devices to meet the import of List files/
Export, data logging functions, etc.
•
Standard build-in USB/CAN/LAN/digital IO communication interface, option-
al GPIB/analog & RS232
Voltage Model
Level
IT-M3901D-10-170
IT-M3903D-10-340
10V
IT-M3905D-10-510
IT-M3910D-10-1020
IT-M3902D-32-80
IT-M3904D-32-160
32V
IT-M3906D-32-240
IT-M3912D-32-480
IT-M3902D-80-40
IT-M3904D-80-80
80V
IT-M3906D-80-120
IT-M3912D-80-240
300V IT-M3902D-300-20
Copyright © Itech Electronic Co., Ltd.
Current Power
170A 1.7kW
340A 3.4kW
510A 5.1kW
1020A 10.2kW
80A 2kW
160A 4kW
240A 6kW
480A 12kW
40A 2kW
80A 4kW
120A 6kW
240A 12kW
20A 2kW
Quick Reference
Height
1U
1U
1U
2U
1U
1U
1U
2U
1U
1U
1U
2U
1U
2
