M3904D-80-80 - ITech IT-M3900D Series User Manual

Command Re-
sponse Time
Parallel Number
Working
Temperature
Storage
Temperature
IP
Isolation DC to GND
Isolation AC to GND
Cooling
Dimension
（D*W*H）
Weight( net)
6.1.10 IT-M3904D-80-80
Parameter
Rated value
Setup Resolution
Read Back
Resolution
*1: The ripple is got under three-phase AC input.
*2: At low voltage input, the set power will decrease. For more information,
please contact ITECH.
Voltage
Current
Power
Resistance in series
（CV priority）
Voltage
Current
Power
Resistance in series
（CV priority）
Voltage
Current
Power
Copyright © Itech Electronic Co., Ltd.
Optional: GPIB/Analog&RS232
0.1ms
≤16
0～40℃
-10℃～70℃
IP20
300Vdc
3500Vdc
Air
744.22mm*459mm*56.81mm
10kg
IT-M3904D-80-80
Technical Specification
0～80V
0～80A
0～4000W
0～0.3Ω
0.001V
0.01A
1W
0.001Ω
0.001V
0.01A
1W
132
