Storage
Temperature
IP
Isolation DC to
GND
Isolation AC to
GND
Cooling
Dimension ( mm)
Weight( net)
6.1.23 IT-M3906D-800-24
Parameter
Rated value
Setup Resolution
Read Back
Resolution
Setup Accuracy
*1: The ripple is got under three-phase AC input.
*2: At low voltage input, the set power will decrease. For more information,
please contact ITECH.
Voltage
Current
Power
Resistance in ser-
ies （CV priority）
Voltage
Current
Power
Resistance in ser-
ies （CV priority）
Voltage
Current
Power
Voltage
Current
Power
Resistance in ser-
ies （CV priority）
Copyright © Itech Electronic Co., Ltd.
-10℃～70℃
IP20
1000Vdc
3500Vdc
Air
744.22mm*459mm*56.81mm
12.5kg
IT-M3906D-800-24
0W～6000W
≤0.03% + 0.03%FS
≤0.1% + 0.1%FS
≤0.5% + 0.5%FS
Technical Specification
0～800V
0A～24A
0～1Ω
0.01V
0.001A
1W
0.01Ω
0.01V
0.001A
1W
≤1%FS
