Parameter
Other parameters:
AC Input *2
Max. apparent
power
Max. input current
Max. efficiency
Power Factor
DC component
Current harmonics
Standard Interface
Command Re-
sponse Time
Parallel Number
Working
Temperature
Storage
Temperature
IP
Isolation DC to GND
Isolation AC to GND
Cooling
Dimension
（D*W*H）
Weight( net)
current monitor
voltage program
voltage monitor
Grid voltage range
Frequency
Optional: GPIB/Analog&RS232
Copyright © Itech Electronic Co., Ltd.
IT-M3904D-80-80
Current 0A to 80A corresponds to external moni-
toring voltage 0V to 10V
External programming voltage 0 to 80V Corre-
sponding voltage 0 to 10V
Voltage 0 to 80V corresponds to external monitor-
ing voltage 0 to 10V
3phase 200V～480V
Single phase 100V～240V
4.5kVA
12.5Aac
92%
0.99
≤0.2A
≤3%
Standard: USB/LAN/CAN/IO
0.1ms
≤16
0～40℃
-10℃～70℃
IP20
300Vdc
3500Vdc
Air
744.22mm*459mm*56.81mm
12.5kg
Technical Specification
50/60Hz
