11
D-STAR OPERATION (ADVANCED)
Viewing received call signs
When you receive a DV call, the calling station and
the repeater call signs are saved Up to 50 calls can
be saved When you receive the 51st call, the oldest
call history is deleted
D Viewing the call signs on the RX History
screen
1 Open the RX HISTORY screen
» 2 > CD
2 Touch an RX history memory to view the details
L Information
• The RX history number, the caller's name (or call
sign), destination, RX message, Received signal
mode, RX date and time, "GW," and "GPS" are
displayed
• "GW" is displayed when a Gateway call is received
• "GPS" is displayed when the received call includes
position data
• "UP" is displayed when a repeater uplink signal is
received
• Touch [RX>CS] to temporarily enter the received call
sign into "TO"
• In the QUICK MENU screen, you can select the
following options
Call Sign Display:
Name Display:
Add to RPT List:
Add to Your Memory: Adds the caller station's call sign
Delete:
Delete All:
RX HISTORY screen (RX01)
Caller station* 2
Received signal mode
LA note may be
displayed after "/"
RX message
History
number
Called
station
D-PRS information
• Compass direction
• Distance
• D-PRS symbol
* 1 The icon differs, depending on the D-PRS TX format.
GPS: Position OBJ: Object
ITEM: Item WX: Weather
* When a name is not entered in the DV/DD Memory, the call sign
2
is displayed
The received data is displayed in
the Call Sign Display mode
The received data is displayed in
the Name Display mode
Adds the repeater's call sign to
the Repeater List
to Your Call Sign
Deletes the selected RX history
Deletes all RX histories
Displayed when a
Gateway call is received
* 1
Repeater name of
the called station
Received
date and time
3 Touch [DETAIL]
• Displays the RX history detail screen
• Rotate
<1st page>
• CALLER: Displays the caller station's name*
any note entered after the call sign
• CALLED: Displays the called station's name*
L "CQCQCQ" is displayed when receiving
<2nd page>
• RXRPT1: Displays the repeater's name*
accessed by the caller station If the
received call was a Gateway call, this
item displays the gateway call sign of the
repeater you received the call from
• RX RPT2: Displays the repeater's name*
received the call from
L The operating frequency is displayed instead of the
above items when the call was not through a repeater
(Simplex call)
11-13
to select the page
a Local Area call or Gateway call
and
2

2
that was
2
2 you
