Levelflex FMP55 FOUNDATION Fieldbus
Name
eop_map_point_number
factory_data_valid
fieldbus_type
full_scale
init_map_point_number
max_not_assoc_track
ref_max_dist
ref_min_dist
line_mapping_accuracy
mapping_curve_left_margin
device_calib_changed
echo_thresh_attenuat_const_ee Threshold attenuation constant 134
echo_threshold_far_ee
echo_thresh_inactive_len
echo_threshold_near_ee
present_probe_length_ee
reset_appl_para_chg_flags
reset_dyn_persistent
locking_status
decimal_places_menu
access_status_tooling
level_linearized
bdt_transferred_ctrl
bdt_cfg_rdwr_ctrl
Endress+Hauser
Label
Fieldbus Type
Ref max. dist.
Ref min. dist.
Line mapping accuracy
Mapping curve left margin
Locking status
Decimal places menu
Access status tooling
Level linearized
9.7

Methods

The FOUNDATION Fieldbus Specification includes the use of methods to make device
operation easier. A method is a sequence of interactive steps to be carried out in the
specified order so as to configure certain device functions.
The following methods are available for the device:
• Restart
This method is located in the Resource Block and directly prompts the setting of the
Device reset parameter. This resets the device configuration to a defined state.
• ENP Restart
This method is located in the Resource Block and directly prompts the setting of the
parameters of the Electronic Name Plate (ENP).
• Setup
This method is located in the SETUP Transducer Block and allows to set the most
important parameters in this block for device configuration (measuring units, type of
tank or vessel, type of medium, empty and full calibration).
• Linearization
This method is located in the ADV_SETUP Transducer Block and allows to manage the
linearization table by which the measured value is converted into volume, mass or flow.
• Self Check
This method is located in the EXPERT_CONFIG Transducer Block and prompts the device
self check parameters.
Integration into a FOUNDATION Fieldbus network
Index Data type Size (Bytes) Storage Class Write access MODE_BLK
116 UINT16 2
123 UINT8 1
144 ENUM8 1
115 FLOAT 4
117 UINT16 2
118 UINT16 2
119 FLOAT 4
120 FLOAT 4
130 FLOAT 4
131 FLOAT 4
133 ENUM16 2
FLOAT 4
135 FLOAT 4
137 FLOAT 4
136 FLOAT 4
138 FLOAT 4
139 ENUM16 2
140 ENUM16 2
142 BIT_ENUM16 2
96 ENUM16 2
141 ENUM16 2
147 FLOAT 4
197 UINT8 1
196 UINT16 2
Static x
Static
Static
Static x
Static x
Static x
Static x
Static x
Static x
Static x
Static x
Dynamic x
Static x
Static x
Static x
Static x
Static x
Static x
Dynamic
Static x
Static
Dynamic
Static x
Static x
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
