Operating menu
Additional information
DC value lower medium
Navigation
Prerequisite
Description
User entry
8) The specific capacitance of the media depends on the DC value and the geometry of the probe, which may differ noticeably. For rod probes < 2 m,
the probe geometry is measured after production and the resulting specific capacitance for conductive media is preset on delivery.
142
Meaning of the options
• Special: automatic DC
• Condition:
The specific capacitance (pF/m) is known.
• Signal evaluation:
As long as a clear interface is detected, both the total and the interface level are
determined via the Guided Radar. The dielectric constant of the upper medium is
continuously adjusted. If an emulsion layer is present, the total level is determined via
the Guided Radar whereas the interface level is determined via the Capacitance
Measurement.
• Build up
• Condition:
The dielectric constant of the upper medium and the specific capacitance (pF/m) are
8)
known.
• Signal evaluation:
As long as a clear interface is detected, the interface level is determined via the Guided
Radar as well as via the Capacitance Measurement. If these two values start to diverge
from each other due to build-up formation, an error message is generated. If an
emulsion layer is present, the total level is determined via the Guided Radar whereas
the interface level is determined via the Capacitance Measurement.
• Standard
• Condition:
The dielectric constant of the upper medium is known.
• Signal evaluation:
As long as a clear interface is detected, the specific capacitance (pF/m) is continuously
adjusted. Therefore build-up has only little influence on the measurement. If an
emulsion layer is present, the total level is determined via the Guided Radar whereas
the interface level is determined via the Capacitance Measurement.
• Oil/Water condensate
• Condition:
The dielectric constant of the upper medium and the specific capacitance (pF/m) are
8)
known.
• Signal evaluation:
The total level is always determined via the Guided Radar. The interface level is always
determined via the Capacitance Measurement.
 Setup → Advanced setup → Interface → DC lower medium
Operating mode (→  126) = Interface or Interface with capacitance
Specify the dielectric constant ε
1 to 100
Levelflex FMP55 FOUNDATION Fieldbus
8)
of the lower medium.
r

