16.1.3

Centering star

Accessories Description
Centering star PFA
•  16.4 mm (0.65 in)
•  37 mm (1.46 in)
suitable for
FMP55
A
B
The centering star is suitable for probes with a rod diameter of 8 mm (0.3 in),
12 mm (0.47 in) and 16 mm (0.63 in) (including coated rod probes) and can be
used in pipes from DN40 to DN50. See also Operating Instructions
BA00378F/00/A2.
• Material: PFA
• Permitted process temperature range: –200 to +250 °C (–328 to +482 °F)
• Order number

For probe 8 mm (0.3 in)
For probes 12 mm (0.47 in) and 16 mm (0.63 in)
• Probe 8 mm (0.3 in) : 71162453
• Probe 12 mm (0.47 in): 71157270
• Probe 16 mm (0.63 in): 71069065
The PFA centering star can also be ordered directly with the device (Levelflex
product structure, feature 610 "Accessory mounted", option OE).
Accessories
A0014577
