Operating menu
148
"Linearization" submenu
L
1
I
 37 Linearization: Conversion of the level and, if applicable, interface into a volume or a weight; the
conversion depends on the vessel shape
1 Selection of linearization type and unit
2 Configuration of the linearization
A Linearization type (→  151) = None
B Linearization type (→  151) = Linear
C Linearization type (→  151) = Table
D Linearization type (→  151) = Pyramid bottom
E Linearization type (→  151) = Conical bottom
F Linearization type (→  151) = Angled bottom
G Linearization type (→  151) = Horizontal cylinder
H Linearization type (→  151) = Sphere
I For "Operating mode (→  126)" = "Interface" or "Interface with capacitance": interface before linearization
(measured in the level unit)
I' For "Operating mode (→  126)" = "Interface" or "Interface with capacitance": interface after linearization
(corresponds to volume or weight)
L Level before linearization (measured in level unit)
L' Level linearized (→  154) (corresponds to volume or weight)
M Maximum value (→  154)
d Diameter (→  154)
h Intermediate height (→  155)
Levelflex FMP55 FOUNDATION Fieldbus
2
A
L
100%
B
0%
M
L'
L
100%
L2
C
L1
0%
L'1 L'2 L'
L
100%
D
0%
M L'
L
100%
E
0%
M L'
L
100%
F
0%
M L'
L
100%
G
0%
M L'
L
100%
H
0%
M L'
L'
I'
A0016084
