Accessories
Accessories Description
Mounting bracket for
electronics housing
 32
A
B

106
16.1.2 Mounting bracket for electronics housing
A
122 (4.8)
161 (6.34)
Mounting bracket for electronics housing; engineering unit: mm (in)
Wall mounting
Post mounting
With "remote sensor" device versions (see feature 060 in the product structure), the mounting bracket is included in
the scope of delivery. However, it can also be ordered separately as an accessory (order number: 71102216).
Levelflex FMP55 FOUNDATION Fieldbus
B
ø42...60
(1.65...2.36)
127...140
(5...5.51)
162...175
(6.38...6.89)
A0014793
