1.2.4

Symbols for certain types of information and graphics

 Permitted
Procedures, processes or actions that are permitted
 Preferred
Procedures, processes or actions that are preferred
 Forbidden
Procedures, processes or actions that are forbidden
 Tip
Indicates additional information
Reference to documentation
Reference to graphic
Notice or individual step to be observed
,
,
1.
2.
3.
Series of steps
Result of a step
Visual inspection
Operation via operating tool
Write-protected parameter
1, 2, 3, ...
Item numbers
A, B, C, ...
Views
 Safety instructions
Observe the safety instructions contained in the associated Operating Instructions
 Temperature resistance of the connection cables
Specifies the minimum value of the temperature resistance of the connection cables
