Page 1 Products Solutions Services BA01054F/00/EN/04.16 71344076 01.01.zz (Device software) Operating Instructions Levelflex FMP55 FOUNDATION Fieldbus Guided wave radar...
Page 2 Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
Page 3: Table Of Contents
Mounting the device ....31 Device identification and addressing ..62 6.2.1 Required mounting tools ..31 Endress+Hauser...
Page 4 (CHANNEL) in an AI Block ....64 12.8.3 Configurable area ....96 Index tables of Endress+Hauser parameters . . 65 12.8.4 Transmission of the event messages 9.6.1...
Page 5 17.4.9 "Heartbeat" submenu ... . 207 Index ....... . . 208 Endress+Hauser...
Page 6: Important Document Information
Important document information Levelflex FMP55 FOUNDATION Fieldbus Important document information Document function These Operating Instructions contain all the information that is required in various phases of the life cycle of the device: from product identification, incoming acceptance and storage, to mounting, connection, operation and commissioning through to troubleshooting, maintenance and disposal.
Page 7: Tool Symbols
Levelflex FMP55 FOUNDATION Fieldbus Important document information 1.2.3 Tool symbols Symbol Meaning Torx screwdriver A0013442 Flat blade screwdriver A0011220 Cross-head screwdriver A0011219 Allen key A0011221 Hexagon wrench A0011222 1.2.4 Symbols for certain types of information Symbol Meaning Permitted Procedures, processes or actions that are permitted.
Page 8: Symbols At The Device
Important document information Levelflex FMP55 FOUNDATION Fieldbus Symbol Meaning Hazardous area Indicates a hazardous area. Safe area (non-hazardous area) Indicates the non-hazardous area. 1.2.6 Symbols at the device Symbol Meaning Safety instructions Observe the safety instructions contained in the associated Operating Instructions.
Page 9: Supplementary Documentation
For an overview of the scope of the associated Technical Documentation, refer to the following: • The W@M Device Viewer : Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. Endress+Hauser...
Page 10: Safety Instructions (Xa)
Important document information Levelflex FMP55 FOUNDATION Fieldbus 1.3.1 Safety Instructions (XA) Depending on the approval, the following Safety Instructions (XA) are supplied with the device. They are an integral part of the Operating Instructions. Feature 010 Approval Available for Feature 020: "Power Supply; Output"...
Page 11 Levelflex FMP55 FOUNDATION Fieldbus Important document information Feature 010 Approval Available for Feature 020: "Power Supply; Output" NEPSI Ex ia IIC T6 Ga/Gb, Ex iaD 20/21 T85…90°C FMP55 XA00638F XA00638F XA00638F XA00644F XA00638F NEPSI Ex d[ia] IIC T6 Ga/Gb, DIP A20/21 T85…90°C...
Page 12 Important document information Levelflex FMP55 FOUNDATION Fieldbus Ex-marking in case of connected FHX50 remote display If the device is prepared for the remote display FHX50 (product structure: feature 030: Display, Operation", option L or M), the Ex marking of some certificates changes according to the following table Feature 010 ("Approval") Feature 030 ("Display, Operation") Ex-marking...
Page 13: Basic Safety Instructions
The manufacturer is not liable for damage caused by improper or non-designated use. Verification for borderline cases: ‣ For special measured materials and cleaning agents, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of wetted materials, but does not accept any warranty or liability.
Page 14: Workplace Safety
The measuring system meets the legal requirements of the applicable EC guidelines. These are listed in the corresponding EC Declaration of Conformity together with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. 2.5.2 EAC conformity The measuring system meets the legal requirements of the applicable EAC guidelines.
Page 15: Product Description
Levelflex FMP55 FOUNDATION Fieldbus Product description Product description Product design 3.1.1 Levelflex FMP51/FMP52/FMP54/FMP55 A0012399  1 Design of the Levelflex Electronics housing Process connection (here as an example: flange) Rope probe End-of-probe weight Rod probe Coax probe Endress+Hauser...
Page 16: Electronics Housing
Product description Levelflex FMP55 FOUNDATION Fieldbus 3.1.2 Electronics housing A0012422  2 Design of the electronics housing Electronics compartment cover Display module Main electronics module Cable glands (1 or 2, depending on instrument version) Nameplate I/O electronics module Terminals (pluggable spring terminals)
Page 17: Registered Trademarks
Levelflex FMP55 FOUNDATION Fieldbus Product description Registered trademarks FOUNDATION Fieldbus Registered trademark of the FieldComm Group, Austin, Texas, USA KALREZ ® , VITON ® Registered trademark of DuPont Performance Elastomers L.L.C., Wilmington, USA TEFLON ® Registered trademark of E.I. DuPont de Nemours & Co., Wilmington, USA TRI CLAMP ®...
Page 18: Incoming Acceptance And Product
• Enter the serial number from the nameplates into the Endress+Hauser Operations App or scan the 2-D matrix code (QR code) on the nameplate with the Endress+Hauser Operations App: all the information for the measuring device is displayed. Endress+Hauser...
Page 19: Nameplate
Levelflex FMP55 FOUNDATION Fieldbus Incoming acceptance and product identification 4.2.1 Nameplate 92 (3.62) Order code: Ser. no.: Ext. ord. cd.: MWP: LN = Lref = Mat.: DeviceID: Dev.Rev.: if modification see sep. label Date: mm (in) A0010725  3 Nameplate of the Levelflex...
Page 20: Storage, Transport
Storage, Transport Levelflex FMP55 FOUNDATION Fieldbus Storage, Transport Storage conditions • Permitted storage temperature: –40 to +80 °C (–40 to +176 °F) • Use the original packaging. Transport product to the measuring point WARNING Housing or probe may be damaged or break away.
Page 21 Levelflex FMP55 FOUNDATION Fieldbus Storage, Transport A0015471 Endress+Hauser...
Page 22: Mounting
A0011281  4 Mounting position of Levelflex FMP55 • Rod probes / rope probes: must be mounted in a stilling well or bypass →  27. • Coax probes: can be mounted at an arbitrary distance from the wall of the vessel.
Page 23: Applications With Restricted Mounting Space
Levelflex FMP55 FOUNDATION Fieldbus Mounting 6.1.2 Applications with restricted mounting space Mounting with remote sensor The device version with a remote sensor is suited for applications with restricted mounting space. In this case the electronics housing is mounted at a separate position from which it is easier accessible.
Page 24: Notes On The Mechanical Load Of The Probe
Mounting Levelflex FMP55 FOUNDATION Fieldbus 6.1.3 Notes on the mechanical load of the probe Tensile load limit of rope probes Sensor Feature 060 Probe Tensile load limit [kN] FMP55 NA, ND Rope 4mm (1/6") PFA>316 Bending strength of rod probes...
Page 25: Mounting Cladded Flanges
Levelflex FMP55 FOUNDATION Fieldbus Mounting 6.1.4 Mounting cladded flanges • Use flange screws according to the number of flange holes. • Tighten the screws with the required torque (see table). • Retighten the screws after 24 hours or after the first temperature cycle.
Page 26: Securing The Probe
Mounting Levelflex FMP55 FOUNDATION Fieldbus 6.1.5 Securing the probe Securing coax probes For WHG approvals: For probe lengths ≥ 3 m (10 ft) a support is required. A0012608 Coax probes can be supported at any point of the outer tube.
Page 27: Special Mounting Conditions
Levelflex FMP55 FOUNDATION Fieldbus Mounting 6.1.6 Special mounting conditions Bypasses and stilling wells In bypass and stilling well applications it is recommended to use a centering disks or stars. A0014129 Mounting in a stilling well Mounting in a bypass Minimum distance between end of probe and lower edge of the bypass; see table below...
Page 28 With heat insulated tanks the bypass should also be insulated in order to prevent condensate formation. For information on bypass solutions from Endress+Hauser please contact your Endress+Hauser sales representative. Endress+Hauser...
Page 29 Levelflex FMP55 FOUNDATION Fieldbus Mounting Underground tanks A0014142 Use a coax probe for nozzles with large diameters in order to avoid reflections at the nozzle wall. Non-metallic vessels When mounting Levelflex in a non-metallic vessel, use a coax probe. Endress+Hauser...
Page 30 Mounting Levelflex FMP55 FOUNDATION Fieldbus Vessels with heat insulation If process temperatures are high, the device must be included in normal tank insulation to prevent the electronics heating up as a result of heat radiation or convection. The insulation may not exceed beyond the points labeled "MAX" in the drawings.
Page 31: Mounting The Device
Levelflex FMP55 FOUNDATION Fieldbus Mounting Mounting the device 6.2.1 Required mounting tools • For flanges and other process connections: appropriate mounting tools • To turn the housing: Hexagonal wrench 8 mm 6.2.2 Mounting the device Flange mounting If a seal is used, be sure to use unpainted metal bolts to ensure good electrical contact between probe flange and process flange.
Page 32 Mounting Levelflex FMP55 FOUNDATION Fieldbus CAUTION The plugs of the connection cable may be damaged by mechanical stress. ‣ Mount the probe and the electronics housing tightly before connecting the cable. ‣ Lay the cable such that it is not exposed to mechanical stress. Minimum bending radius: 100 mm (4").
Page 33: Turning The Transmitter Housing
Levelflex FMP55 FOUNDATION Fieldbus Mounting 6 Nm 6 Nm (4.42 lbf ft) (4.42 lbf ft) = 100 (4) = 100 (4) 6 Nm 6 Nm (4.42 lbf ft) (4.42 lbf ft) A0014794  7 Connecting the cable. There are the following possibilities:...
Page 34: Turning The Display Module
Mounting Levelflex FMP55 FOUNDATION Fieldbus 6.2.5 Turning the display module 3 mm A0013905 1. If present: Loosen the screw of the securing clamp of the electronics compartment cover using an Allen key and turn the clamp 90° conterclockwise. 2. Unscrew cover of the electronics compartment from the transmitter housing.
Page 35: Post-Installation Check
Levelflex FMP55 FOUNDATION Fieldbus Mounting Post-installation check Is the device undamaged (visual inspection)? Does the device conform to the measuring point specifications? For example: • Process temperature • Process pressure (refer to the chapter on "Material load curves" of the "Technical Information"...
Page 36: Electrical Connection
Electrical connection Levelflex FMP55 FOUNDATION Fieldbus Electrical connection Connection conditions 7.1.1 Terminal assignment PROFIBUS PA / FOUNDATION Fieldbus A0011341  8 Terminal assignment PROFIBUS PA / FOUNDATION Fieldbus Without integrated overvoltage protection With integrated overvoltage protection Cable screen: Observe cable specifications...
Page 37: Cable Specification
≥60 °C (140 °F): use cable for temperature T +20 K. FOUNDATION Fieldbus Endress+Hauser recommends using twisted, shielded two-wire cables. For further information on the cable specifications, see Operating Instructions BA00013S "FOUNDATION Fieldbus Overview", FOUNDATION Fieldbus Guideline and IEC 61158-2 (MBP).
Page 38: Device Plug Connectors
Electrical connection Levelflex FMP55 FOUNDATION Fieldbus 7.1.3 Device plug connectors For the versions with fieldbus plug connector (M12 or 7/8"), the signal line can be connected without opening the housing. Pin assignment of the M12 plug connector Meaning Signal +...
Page 39: Power Supply
< 1.5 pF Nominal arrest impulse voltage (8/20 μs) 10 kA External overvoltage protection HAW562 or HAW569 from Endress+Hauser are suited as external overvoltage protection. For detailed information please refer to the following documents: • HAW562: TI01012K • HAW569: TI01013K...
Page 40: Connecting The Device
Electrical connection Levelflex FMP55 FOUNDATION Fieldbus Connecting the device WARNING Explosion hazard! ‣ Comply with the relevant national standards. ‣ Observe the specifications in the Safety Instructions (XA). ‣ Only use the specified cable glands. ‣ Check whether the supply voltage matches the specifications on the nameplate.
Page 41: Pluggable Spring-Force Terminals
Levelflex FMP55 FOUNDATION Fieldbus Electrical connection A0013837 Connect the cable in accordance with the terminal assignment →  36. 8. When using screened cable: Connect the cable screen to the ground terminal. 9. Screw the cover onto the connection compartment.
Page 42 Electrical connection Levelflex FMP55 FOUNDATION Fieldbus If required: Is the protective earth connected correctly ? If supply voltage is present: Is the device ready for operation and do values appear on the display module? Are all housing covers installed and firmly tightened?
Page 43: Operation Options
Levelflex FMP55 FOUNDATION Fieldbus Operation options Operation options Overview 8.1.1 Local operation Operation Pushbuttons Touch Control with Order code for Option C "SD02" Option E "SD "Display; Operation" A0032219 A0032221 Display 4-line display 4-line display elements white background lighting; switches to red in...
Page 44: Operation With Remote Display And Operating Module Fhx50
Operation options Levelflex FMP55 FOUNDATION Fieldbus 8.1.2 Operation with remote display and operating module FHX50 A0013137  11 FHX50 operating options Housing of the remote display and operating module FHX50 Display and operating module SD02, push buttons; cover must be removed Display and operating module SD03, optical keys;...
Page 45 High Speed Ethernet FF-H1 FOUNDATION Fieldbus-H1 Linking Device FF-HSE/FF-H1 Bus Power Supply Safety Barrier Bus Terminator Via service interface (CDI) A0014019 Service interface (CDI) of the measuring device (= Endress+Hauser Common Data Interface) Commubox FXA291 Computer with "FieldCare" operating tool Endress+Hauser...
Page 46: Structure And Function Of The Operating Menu
Operation options Levelflex FMP55 FOUNDATION Fieldbus Structure and function of the operating menu 8.2.1 Structure of the operating menu Menu Submenu / Meaning parameter Language Defines the operating language of the on-site display. Commissioning Opens the interactive wizard for a guided commissioning of the device.
Page 47 Levelflex FMP55 FOUNDATION Fieldbus Operation options Menu Submenu / Meaning parameter Communication Contains all parameters needed to configure the digital communication interface. Diagnostics Contains all parameters needed to detect and analyze operational errors. In case of operation via operating tools (e.g. FieldCare), the "Language" parameter is located at "Setup → ...
Page 48: User Roles And Related Access Authorization
Operation options Levelflex FMP55 FOUNDATION Fieldbus 8.2.2 User roles and related access authorization The two user roles Operator and Maintenance have different write access to the parameters if a device-specific access code has been defined. This protects the device configuration via the local display from unauthorized access →  49.
Page 49: Write Protection Via Access Code
Levelflex FMP55 FOUNDATION Fieldbus Operation options 8.2.3 Write protection via access code Using the device-specific access code, the parameters for the measuring device configuration are write-protected and their values can no longer be changed via local operation. Define access code via local display 1.
Page 50: Disabling Write Protection Via Access Code
Operation options Levelflex FMP55 FOUNDATION Fieldbus 8.2.4 Disabling write protection via access code If the -symbol appears on the local display in front of a parameter, the parameter is write-protected by a device-specific access code and its value cannot be changed at the moment using the local display →...
Page 51: Write Protection Via Write Protection Switch
Levelflex FMP55 FOUNDATION Fieldbus Operation options 8.2.6 Write protection via write protection switch Unlike parameter write protection via a user-specific access code, this allows write access to the entire operating menu - except for the "Contrast display" parameter - to be locked.
Page 52 Operation options Levelflex FMP55 FOUNDATION Fieldbus 4. Installing the lock switch (WP) on the main electronics module in the ON position enables the hardware write protection. Installing the lock switch (WP) on the main electronics module in the OFF position (factory setting) disables the hardware write protection.
Page 53: Enabling And Disabling The Keypad Lock
Levelflex FMP55 FOUNDATION Fieldbus Operation options 8.2.7 Enabling and disabling the keypad lock The keypad lock allows to disable access to the entire operating menu via local operation. Thus navigating through the operating menu or modifying the values of individual parameters is no longer possible.
Page 54: Display And Operating Module
Operation options Levelflex FMP55 FOUNDATION Fieldbus Display and operating module 8.3.1 Display appearance User ABC_ DEFG HIJK PQRS TUVW LMNO A0012635  13 Appearance of the display and operation module for on-site operation Measured value display (1 value max. size) 1.1 Header containing tag and error symbol (if an error is active)
Page 55 Levelflex FMP55 FOUNDATION Fieldbus Operation options Display symbols for the submenus Symbol Meaning Display/operation Is displayed: • in the main menu next to the selection "Display/operation" A0011975 • in the header, if you are in the "Display/operation" menu Setup Is displayed: •...
Page 56 Operation options Levelflex FMP55 FOUNDATION Fieldbus Measured value symbols Symbol Meaning Measured values Level A0011995 Distance A0011996 Current output A0011998 Measured current A0011999 Terminal voltage A0012106 Temperature of the electronics or the sensor A0012104 Measuring channels Measuring channel 1 A0012000...
Page 57: Operating Elements
Levelflex FMP55 FOUNDATION Fieldbus Operation options 8.3.2 Operating elements Meaning Minus key For menu, submenu Moves the selection bar upwards in a picklist. A0013969 For text and numeric editor In the input mask, moves the selection bar to the left (backwards).
Page 58: Entering Numbers And Text
Operation options Levelflex FMP55 FOUNDATION Fieldbus 8.3.3 Entering numbers and text Numeric editor Text editor User ABC_ DEFG HIJK LMNO PQRS TUVW A0013999 A0013941 Editing view Display area of the entered values Input mask Operating elements Input mask The following input symbols are available in the input mask of the numeric and text editor:...
Page 59 Levelflex FMP55 FOUNDATION Fieldbus Operation options Confirms selection. A0013985 Switches to the selection of the correction tools. A0013987 Exits the input without applying the changes. A0013986 Clears all entered characters. A0014040 Correction symbols under Clears all entered characters. A0013989 Moves the input position one position to the right.
Page 60: Opening The Context Menu
Operation options Levelflex FMP55 FOUNDATION Fieldbus 8.3.4 Opening the context menu Using the context menu, the user can call up the following menus quickly and directly from the operational display: • Setup • Conf. backup disp. • Simulation Calling up and closing the context menu The user is in the operational display.
Page 61: Envelope Curve On The Display And Operating Module
Levelflex FMP55 FOUNDATION Fieldbus Operation options 8.3.5 Envelope curve on the display and operating module In order to assess the measuring signal, the envelope curve and - if a mapping has been recorded - the mapping curve can be displayed:...
Page 62: Integration Into A Foundation
Integration into a FOUNDATION Fieldbus network Levelflex FMP55 FOUNDATION Fieldbus Integration into a FOUNDATION Fieldbus network Device Description (DD) You require the following to configure a device and integrate it into an FF network: • An FF configuration program • The Cff file (Common File Format: *.cff) •...
Page 63: Block Model
Levelflex FMP55 FOUNDATION Fieldbus Integration into a FOUNDATION Fieldbus network – EH_Levelflex_xxxxxxxxxx – RESOURCE_xxxxxxxxxxx (RB2) SETUP_ xxxxxxxxxxx (TRDSUP) ADV_SETUP_ xxxxxxxxxxx (TRDASUP) DISPLAY_ xxxxxxxxxxx (TRDDISP) DIAGNOSTIC_ xxxxxxxxxxx (TRDDIAG) EXPERT_CONFIG_ xxxxxxxxxxx (TRDEXP) EXPERT_INFO_ xxxxxxxxxxx (TRDEXPIN) SERVICE_SENSOR_ xxxxxxxxxxx (TRDSRVSB) SERVICE_INFO_ xxxxxxxxxxx (TRDSRVIF) DATA_TRANSFER_...
Page 64: Block Configuration When Device Is Delivered
The guideline provides an overview of the standard function blocks that are described in FOUNDATION Fieldbus Specifications FF 890 - 894. It is designed to help operators use the blocks implemented in the Endress+Hauser field devices. 9.4.2 Block configuration when device is delivered Device_01 4841.000...
Page 65: Index Tables Of Endress+Hauser Parameters
Levelflex FMP55 FOUNDATION Fieldbus Integration into a FOUNDATION Fieldbus network Channel Measured value Interface distance Calculated DC value Terminal voltage Sensor debug 32785 Absolute EOP amplitude 32786 Absolute echo amplitude 32787 Absolute interface amplitude 32856 Distance 32885 Elektronic temperature 32938...
Page 66: Advanced Setup Transducer Block
Integration into a FOUNDATION Fieldbus network Levelflex FMP55 FOUNDATION Fieldbus Name Label Index Data type Size Storage Write MODE_BL Description (Bytes) Class access distance_unit Distance unit ENUM16 Static interface Interface FLOAT Dynamic level_unit Level unit ENUM16 Static output_unit_after_lineariza Unit after linearization...
Page 67: Display Transducer Block
Levelflex FMP55 FOUNDATION Fieldbus Integration into a FOUNDATION Fieldbus network Name Label Index Data type Size Storage Write MODE_BL Description (Bytes) Class access level_correction Level correction FLOAT Static level_unit_ro Level unit ENUM16 Static assign_limit Assign limit ENUM16 Static AUTO maximum_value...
Page 68: Diagnostic Transducer Block
Integration into a FOUNDATION Fieldbus network Levelflex FMP55 FOUNDATION Fieldbus Name Label Index Data type Size Storage Write MODE_BLK Description (Bytes) Class access decimal_places_4 Decimal places 4 ENUM16 Static AUTO last_backup Last backup STRING Static AUTO value_1_display Value 1 display...
Page 69: Expert Configuration Transducer
Levelflex FMP55 FOUNDATION Fieldbus Integration into a FOUNDATION Fieldbus network Name Label Index Data type Size Storage Write MODE_BLK Description (Bytes) Class access decimal_places_menu Decimal places menu ENUM16 Static AUTO level_unit_ro Level unit ENUM16 Static operating_mode_ro Operating mode ENUM16 Static...
Page 70 Integration into a FOUNDATION Fieldbus network Levelflex FMP55 FOUNDATION Fieldbus Name Label Index Data type Size (Bytes) Storage Class Write access MODE_BLK history_learning_control History learning ENUM16 Static AUTO history_learning_control History learning control ENUM16 Static AUTO sensor_module Sensor module ENUM16 Static...
Page 71: Expert Information Transducer
Levelflex FMP55 FOUNDATION Fieldbus Integration into a FOUNDATION Fieldbus network 9.6.6 Expert Information Transducer Block The parameters of the Expert Information Transducer Block are described in GP01015F: "Levelflex FMP5x - Description of Device Parameters - FOUNDATION Fieldbus" Name Label Index Data type...
Page 72: Service Sensor Transducer Block
Integration into a FOUNDATION Fieldbus network Levelflex FMP55 FOUNDATION Fieldbus Name Label Index Data type Size (Bytes) Storage Class Write MODE_BLK access sens_temp_status Status ENUM8 Dynamic eop_shift_status Status ENUM8 Dynamic terminal_voltage_1 Terminal voltage 1 FLOAT Dynamic calculated_dc_value Calculated DC value...
Page 73 Levelflex FMP55 FOUNDATION Fieldbus Integration into a FOUNDATION Fieldbus network Name Label Index Data type Size (Bytes) Storage Class Write access MODE_BLK distance_unit_ro Distance unit ENUM16 Static operating_mode_ro Operating mode ENUM16 Static present_probe_length_ro Present probe length FLOAT Dynamic AUTO trend_operation_hours...
Page 74: Methods
Integration into a FOUNDATION Fieldbus network Levelflex FMP55 FOUNDATION Fieldbus Name Label Index Data type Size (Bytes) Storage Class Write access MODE_BLK level_linearized Level linearized FLOAT Dynamic bdt_transferred_ctrl UINT8 Static AUTO bdt_cfg_rdwr_ctrl UINT16 Static AUTO Methods The FOUNDATION Fieldbus Specification includes the use of methods to make device operation easier.
Page 75: Commissioning Via Wizard
Levelflex FMP55 FOUNDATION Fieldbus Commissioning via wizard Commissioning via wizard A wizard guiding the user through the initial setup is available in FieldCare and DeviceCare. 1. Connect the device to FieldCare or DeviceCare →  44. 2. Open the device in FieldCare or DeviceCare.
Page 76: Commissioning Via Operating
Commissioning via operating menu Levelflex FMP55 FOUNDATION Fieldbus Commissioning via operating menu 11.1 Installation and function check Make sure that all final checks have been completed before you start up your measuring point: • Checklist "Post-installation check" →  35 •...
Page 77: Configuration Of An Interface Measurement
Levelflex FMP55 FOUNDATION Fieldbus Commissioning via operating menu 11.3 Configuration of an interface measurement 100% DK (DC ) A0011177  17 Configuration parameters for interface measurements Length of probe Reference pioint of the measurement "Interface distance" parameter (Distance from reference point to lower medium)
Page 78 Commissioning via operating menu Levelflex FMP55 FOUNDATION Fieldbus 11. Navigate to: Setup → Distance  Displays the distance D between the reference point R and the level L 12. Navigate to: Setup → Interface distance  Displays the distance D between the reference point R and the interface L 13.
Page 79: Recording The Reference Curve
Levelflex FMP55 FOUNDATION Fieldbus Commissioning via operating menu 11.4 Recording the reference curve After the configuration of the measurement it is recommended to record the current envelope curve as a reference curve. The reference curve can be used later on in the process for diagnostic purposes.
Page 80: Configuration Of The On-Site Display
Commissioning via operating menu Levelflex FMP55 FOUNDATION Fieldbus 11.5 Configuration of the on-site display 11.5.1 Factory settings of the on-site display for interface measurements Parameter Factory setting for devices with 1 current Factory setting for devices with 2 current output outputs Format display 1 value, max.
Page 81: Configuration Management
Levelflex FMP55 FOUNDATION Fieldbus Commissioning via operating menu 11.6 Configuration management After commissioning, you can save the current device configuration, copy it to another measuring point or restore the previous device configuration. You can do so using the Configuration management parameter and its options.
Page 82: Protection Of The Settings Against Unauthorized Changes
Commissioning via operating menu Levelflex FMP55 FOUNDATION Fieldbus 11.7 Protection of the settings against unauthorized changes There are two ways to protect the settings against unauthorized changes: • Via parameter settings (software locking) →  49 • Via locking switch (hardware locking) →  51...
Page 83: Commissioning
Levelflex FMP55 FOUNDATION Fieldbus Commissioning (block-based operation) Commissioning (block-based operation) 12.1 Function check Carry out a post-installation and a post-connection check as per the checklist before commissioning the device: • "Post-installation check" checklist • "Post-connection check" checklist →  41 12.2...
Page 84: Additional Configuration
Commissioning (block-based operation) Levelflex FMP55 FOUNDATION Fieldbus 12.2.4 Configuring the Analog Input Blocks The device has 2 Analog Input Blocks that can be assigned as required to the various process variables. Default settings Analog Input Block CHANNEL AI 1 32949: Level linearized...
Page 85: Language Selection
Levelflex FMP55 FOUNDATION Fieldbus Commissioning (block-based operation) XD_SCALE OUT_SCALE EU_100 EU_0 EU_100 EU_0 OUT_VALUE A0017338  19 Scaling of the measured value in an AI Block • If you have selected the Direct mode for the L_TYPE parameter, you cannot change the values and units for XD_SCALE and OUT_SCALE.
Page 86 Commissioning (block-based operation) Levelflex FMP55 FOUNDATION Fieldbus 100% DK (DC ) A0011177  20 Configuration parameters for interface measurements R = Reference pioint of the measurement D = Distance of interface (Distance from reference point to lower medium) E = Empty calibration (= zero point)
Page 87 Levelflex FMP55 FOUNDATION Fieldbus Commissioning (block-based operation) Step Block Parameter Action SETUP (TRDSUP) DC value (dc_value) Enter dielectric constant of the upper medium. SETUP (TRDSUP) Empty calibration Enter the distance E (empty_calibration) between the reference point R and the minimum level (0%).
Page 88: Configuration Of The On-Site Display
Commissioning (block-based operation) Levelflex FMP55 FOUNDATION Fieldbus NOTICE Wrong empty capacitance may cause a measuring error. ‣ For rod and rope probes a correct measurement in the 32940: Interface with capacitance operating mode is only possible after the empty capacitance has been determined.
Page 89 Levelflex FMP55 FOUNDATION Fieldbus Commissioning (block-based operation) Options Description 265: Compare The device configuration saved in the display module is compared to the current device configuration of the HistoROM. 32848: Clear backup data The backup copy of the device configuration is deleted from the display module of the device.
Page 90: Configuration Of The Event Behavior According To The Foundation Fieldbus Specification Ff912
Commissioning (block-based operation) Levelflex FMP55 FOUNDATION Fieldbus 12.8 Configuration of the event behavior according to the FOUNDATION Fieldbus specification FF912 The device complies with the FOUNDATION Fieldbus specification FF912. This has - among other things - the following consequences: • The diagnsotic category according to NAMUR recommendation NE107 is transmitted via the fieldbus in a manufacturer-independent form: –...
Page 91: Groups Of Events
Levelflex FMP55 FOUNDATION Fieldbus Commissioning (block-based operation) 12.8.1 Groups of events The diagnostic messages are classified into 16 groups according to the source and severity of the respective event. A default diagnostic category is allocated to each group. Each group is also represented by one bit of the allocation parameters.
Page 92 Commissioning (block-based operation) Levelflex FMP55 FOUNDATION Fieldbus Severity of the Default diagnostic category Source of the Events within the group event event Configuration S441: Current output 1 Process • S801: Energy too low • S825: Operating temperature • S921: Change of reference •...
Page 93: Allocation Parameters
Levelflex FMP55 FOUNDATION Fieldbus Commissioning (block-based operation) 12.8.2 Allocation parameters The allocation of event categories to the event groups is controlled by the allocation parameters. They reside in the RESOURCE (RB2) block: • FD_FAIL_MAP: for the Failure (F) event category •...
Page 94 Commissioning (block-based operation) Levelflex FMP55 FOUNDATION Fieldbus Example The Highest severity / Configuration group contains the messages 410: Data transfer, 411: Up-/Download, 435: Linearization and 437: Configuration incompatible. These messages are no longer to be classified as Failure (F) but as Function check (C).
Page 95 Levelflex FMP55 FOUNDATION Fieldbus Commissioning (block-based operation)  22 Changed state of the "Fail Map" and "Check Map" columns Make sure that for each group the corresponding bit is set to 1 in at least one of the allocation parameters. Otherwise no event category is transmitted with the event message.
Page 96: Configurable Area
Commissioning (block-based operation) Levelflex FMP55 FOUNDATION Fieldbus 12.8.3 Configurable area An event category can be individually defined for the following parameters - irrespective of the group of events they belong to by default. • F941: Echo lost • S942: In safety distance Prior to changing the event category, the event must be allocated to one of the bits 1 to 15.
Page 97: Transmission Of The Event Messages
Levelflex FMP55 FOUNDATION Fieldbus Commissioning (block-based operation) Got to the Offspec Map column and activate the checkbox of the respective bit (in the example: Configurable Area Bit 1). Confirm the selection by pressing the Enter key. A change of the error category of In safety distance does not affect an error which is already present.
Page 98: Diagnostics And Troubleshooting
Diagnostics and troubleshooting Levelflex FMP55 FOUNDATION Fieldbus Diagnostics and troubleshooting 13.1 General trouble shooting 13.1.1 General errors Error Possible cause Remedial action Device does not respond. Supply voltage not connected. Connect the correct voltage. The cables do not contact the Ensure electrical contact between the terminals properly.
Page 99: Parametrization Errors
Levelflex FMP55 FOUNDATION Fieldbus Diagnostics and troubleshooting 13.1.2 Parametrization errors Parametrization errors for level measurements Error Possible cause Remedial action Measured value wrong If measured distance(Setup • Check and adjust the Empty → Distance) matches the real calibration parameter (→  131) if distance: necessary.
Page 100: Diagnostic Information On Local Display
Diagnostics and troubleshooting Levelflex FMP55 FOUNDATION Fieldbus 13.2 Diagnostic information on local display 13.2.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the measured value display. Measured value display in alarm condition...
Page 101 Levelflex FMP55 FOUNDATION Fieldbus Diagnostics and troubleshooting Diagnostics event and event text The fault can be identified using the diagnostics event. The event text helps you by providing information about the fault. In addition, the corresponding symbol is displayed before the diagnostics event.
Page 102: Calling Up Remedial Measures
Diagnostics and troubleshooting Levelflex FMP55 FOUNDATION Fieldbus 13.2.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage Diagnostics 2...
Page 103: Diagnostic Event In The Operating Tool
Levelflex FMP55 FOUNDATION Fieldbus Diagnostics and troubleshooting 13.3 Diagnostic event in the operating tool If a diagnostic event is present in the device, the status signal appears in the top left status in the operating tool along with the corresponding symbol for event level in accordance with NAMUR NE 107: •...
Page 104: Event Logbook
Diagnostics and troubleshooting Levelflex FMP55 FOUNDATION Fieldbus 13.6 Event logbook 13.6.1 Event history A chronological overview of the event messages that have occurred is provided in the Event list submenu Navigation path Diagnostics → Event logbook → Event list A maximum of 100 event messages can be displayed in chronological order.
Page 105 Levelflex FMP55 FOUNDATION Fieldbus Diagnostics and troubleshooting Info number Info name I1092 Trend data deleted I1110 Write protection switch changed I1137 Electronic changed I1151 History reset I1154 Reset terminal voltage min/max I1155 Reset electronic temperature I1156 Memory error trend I1157...
Page 106: Firmware History
Diagnostics and troubleshooting Levelflex FMP55 FOUNDATION Fieldbus 13.7 Firmware history Date Software Modifications Documentation (FMP55, FOUNDATION Fieldbus) version Operating Instructions Description of Parameters Technical Information 04.2012 01.00.zz Original-Software BA01054F/00/EN/01.12 GP01015F/00/EN/01.12 TI01003F/00/EN/14.12 05.2015 01.01.zz • Support of SD03 BA01054F/00/EN/03.15 GP01015F/00/EN/02.15 TI01003F/00/EN/17.15 •...
Page 107: Maintenance
Levelflex FMP55 FOUNDATION Fieldbus Maintenance Maintenance The measuring device requires no special maintenance. 14.1 Exterior cleaning When exterior-cleaning the device, always use cleaning agents that do not attack the surface of the hosuing and the seals. 14.2 Cleaning coax probes For cleaning purposes the ground tube can be stripped of the coaxial probe.
Page 108: Repairs
15.1.1 Repair concept The Endress+Hauser repair concept assumes that the devices have a modular design and that repairs can be done by the Endress+Hauser service or specially trained customers. Spare parts are contained in suitable kits. They contain the related replacement instructions.
Page 109: Spare Parts
The measuring device must be returned if it is need of repair or a factory calibration, or if the wrong measuring device has been delivered or ordered. Legal specifications require Endress+Hauser, as an ISO-certified company, to follow certain procedures when handling products that are in contact with the medium.
Page 110: Accessories
Accessories Levelflex FMP55 FOUNDATION Fieldbus Accessories 16.1 Device-specific accessories 16.1.1 Weather protection cover Accessory Description Weather protection cover A0015466 298.5 (11.8) 273.7 (10.8) 255.1 (10) 164 (6.46) A0015472  25 Weather protection cover; Dimensions: mm (in) 37,8 mm (1,5 in) 54 mm (2,1 in) ...
Page 111: Mounting Bracket For The Electronics
Levelflex FMP55 FOUNDATION Fieldbus Accessories 16.1.2 Mounting bracket for the electronics housing Accessory Description Mounting bracket for the electronics housing ø42...60 (1.65...2.36) 140 (5.5) 122 (4.8) 175 (6.9) 158 (6.2) A0014793  26 Mounting bracket for the electronics housing; Dimensions: mm (in)
Page 112: Remote Display Fhx50
Accessories Levelflex FMP55 FOUNDATION Fieldbus 16.1.4 Remote display FHX50 Accessory Description Remote display FHX50 A0019128 • Material: – Plastics PBT – CF3M (similar to 316L/1.4404) – Aluminum (in preparation) • Ingress protection: IP68 / NEMA 6P and IP66 / NEMA 4x •...
Page 113: Overvoltage Protection
Levelflex FMP55 FOUNDATION Fieldbus Accessories 16.1.5 Overvoltage protection Accessory Description Overvoltage protection for 2-wire-devices OVP10 (1 channel) OVP20 (2 channel) A0021734 Technical data • Resistance per channel: 2 * 0.5 Ω • Threshold DC voltage: 400 to 700 V • Threshold impulse voltage: < 800 V •...
Page 114: Communication-Specific Accessories
Levelflex FMP55 FOUNDATION Fieldbus 16.2 Communication-specific accessories Accessory Description Commubox FXA291 Connects Endress+Hauser field devices with CDI interface (= Endress+Hauser Common Data Interface) to the USB interface of a computer. Order code: 51516983  For details refer to Technical Information TI00405C Accessory...
Page 115: Operating Menu
Levelflex FMP55 FOUNDATION Fieldbus Operating menu Operating menu 17.1 Overview of the operating menu (display module) Navigation  Operating menu Language →  174  Setup →  129 Operating mode →  129 Distance unit →  129 Tank type →...
Page 116 Operating menu Levelflex FMP55 FOUNDATION Fieldbus ‣ Analog inputs ‣ Analog input 1 to 5 →  140 Block tag →  140 Channel →  140 Process Value Filter Time →  141 ‣ →  142 Advanced setup Locking status →...
Page 117 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Diameter →  157 Intermediate height →  158 Table mode →  158 ‣ Edit table Level →  160 Customer value →  160 Activate table →  160 ‣ Safety settings →...
Page 118 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Switch-off delay →  172 Failure mode →  172 Switch status →  172 Invert output signal →  172 ‣ Display →  174 →  174 Language Format display →  174 Value 1 to 4 display →...
Page 119 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Configuration management →  180 Comparison result →  181 ‣ Administration →  183 ‣ Define access code →  185 Define access code →  185 Confirm access code →  185 Device reset →...
Page 120 Operating menu Levelflex FMP55 FOUNDATION Fieldbus ‣ Measured values →  192 Distance →  133 Level linearized →  156 Interface distance →  136 Interface linearized →  157 →  193 Thickness upper layer Terminal voltage 1 →...
Page 121 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Switch status →  204 Simulation device alarm →  204 ‣ Device check →  205 Start device check →  205 Result device check →  205 Last check time →  205 Level signal →...
Page 122: Tool)
Operating menu Levelflex FMP55 FOUNDATION Fieldbus 17.2 Overview of the operating menu (operating tool) Navigation  Operating menu  Setup →  129 Operating mode →  129 Distance unit →  129 Tank type →  130 →  130...
Page 123 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Channel →  140 Process Value Filter Time →  141 ‣ Advanced setup →  142 Locking status →  142 Access status tooling →  142 Enter access code →  143 ‣...
Page 124 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Diameter →  157 Intermediate height →  158 Table mode →  158 Table number →  159 Level →  160 →  160 Level Customer value →  160 Activate table →...
Page 125 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Switch-off delay →  172 Failure mode →  172 Switch status →  172 Invert output signal →  172 ‣ Display →  174 Language →  174 Format display →  174 Value 1 to 4 display →...
Page 126 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Backup state →  181 Comparison result →  181 ‣ Administration →  183 Define access code →  185 Device reset →  183  →  186 Diagnostics Actual diagnostics →  186 Timestamp →...
Page 127 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Interface distance →  136 Interface linearized →  157 Thickness upper layer →  193 Terminal voltage 1 →  194 ‣ Analog inputs ‣ Analog input 1 to 5 →  194 Block tag →...
Page 128 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Level signal →  206 Launch signal →  206 Interface signal →  206 ‣ Heartbeat →  207 Endress+Hauser...
Page 129: Setup" Menu
Levelflex FMP55 FOUNDATION Fieldbus Operating menu 17.3 "Setup" menu • : Marks the navigation path to the parameter via the display and operating module. • : Marks the navigation path to the parameter via an operating tool (e.g. FieldCare). •...
Page 130 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Tank type  Navigation  Setup → Tank type Prerequisite Medium type = Liquid Description Select tank type. Selection • Metallic • Bypass / pipe • Non metallic • Mounted outside • Coaxial Factory setting...
Page 131 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Additional information This parameter roughly specifies the dielectric constant (DC) of the medium. For a more detailed definition of the DC use the Medium property parameter. The Medium group parameter presets the Medium property parameter as follows:...
Page 132 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Full calibration  Navigation  Setup → Full calibr. Description Specify the distance F between the minimum level (0%) and the maximum level (100%). User entry Depending on the probe Factory setting Depending on the probe...
Page 133 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Additional information A0013195  29 Level in case of interface measurements • The unit is defined in the Level unit parameter (→  146). • In case of interface measurements, this parameter always refers to the total level.
Page 134 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Signal quality Navigation  Setup → Signal quality Description Displays the signal quality of the evaluated echo. Additional information Meaning of the display options • Strong The evaluated echo exceeds the threshold by at least 10 mV.
Page 135 DC1 Relative dielectric constant of the upper medium. For dielectric constants (DC values) of many media commonly used in various industries refer to: • the Endress+Hauser DC manual (CP01076F) • the Endress+Hauser "DC Values App" (available for Android and iOS) Interface Navigation  Setup → Interface Prerequisite Operating mode (→...
Page 136 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Interface distance Navigation  Setup → Interface dist. Prerequisite Operating mode (→  129) = Interface or Interface with capacitance Description Displays the measured distance D between the reference point (lower edge of flange or threaded connection) and the interface.
Page 137 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Additional information Meaning of the options • Manual map To be selected if the range of mapping is to be defined manually in the Mapping end point parameter (→  138). In this case it is not necessary to confirm the distance.
Page 138 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Mapping end point  Navigation  Setup → Map. end point Prerequisite Confirm distance (→  136) = Manual map or Distance too small Description Specify new end of the mapping. User entry 0 to 200 000.0 m Factory setting 0.1 m...
Page 139: Mapping" Wizard
Levelflex FMP55 FOUNDATION Fieldbus Operating menu 17.3.1 "Mapping" wizard The Mapping wizard is only available when operating via the local display. When operating via an operating tool, all parameters concerning the mapping are located directly in the Setup menu (→  129).
Page 140: Analog Input 1 To 5" Submenu
Operating menu Levelflex FMP55 FOUNDATION Fieldbus 17.3.2 "Analog input 1 to 5" submenu There is an Analog inputs submenu for every AI block of the device. The AI block is used to configure the measured value transmission to the bus.
Page 141 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Process Value Filter Time Navigation  Setup → Analog inputs → Analog input 1 to 7 → PV Filter Time Description Use this function to enter the filter time specification for the filtering of the unconverted input value (PV).
Page 142: Advanced Setup" Submenu
Operating menu Levelflex FMP55 FOUNDATION Fieldbus 17.3.3 "Advanced setup" submenu Navigation  Setup → Advanced setup Locking status Navigation  Setup → Advanced setup → Locking status Description Indicates the write protection with the highest priority that is currently active.
Page 143 • If no key is pressed for 10 min, or the user switches from the navigation and editing mode back to the measured value display mode, the device automatically locks the write- protected parameters after another 60 s. Please contact your Endress+Hauser Sales Center if you lose your access code. Endress+Hauser...
Page 144 Operating menu Levelflex FMP55 FOUNDATION Fieldbus "Interface" submenu Navigation  Setup → Advanced setup → Interface Process property  Navigation  Setup → Advanced setup → Interface → Process property Description Specify typical rate of change for the interface position.
Page 145 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Additional information Meaning of the options • Special: automatic DC – Condition: The specific capacitance (pF/m) is known. – Signal evaluation: As long as a clear interface is detected, both the total and the interface level are determined via the Guided Radar.
Page 146 For dielectric constants (DC values) of many media commonly used in various industries refer to: • the Endress+Hauser DC manual (CP01076F) • the Endress+Hauser "DC Values App" (available for Android and iOS) The factory setting, ε = 80, is valid for water at 20 °C (68 °F).
Page 147 Levelflex FMP55 FOUNDATION Fieldbus Operating menu A0013220 Suppression of interference echoes at the top end of the probe. Suppression of the level signal in case of a flooded bypass. UB Upper blocking distance Level correction  Navigation  Setup → Advanced setup → Interface → Level correction Description Specify level correction (if required).
Page 148 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Additional information A0013313 UP Interface thickness (= thickness of upper medium) On the local display, the measured interface thickness is indicated together with the manual interface thickness. By comparing these two values the device can automatically adjust the dielectric constant of the upper medium.
Page 149 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Use calculated DC value  Navigation  Setup → Advanced setup → Interface → Use calc. DC Description Specify whether the calculated dielectric constant is to be used. Selection • Save and exit • Cancel and exit...
Page 150 Operating menu Levelflex FMP55 FOUNDATION Fieldbus "Automatic DC calculation" wizard The Automatic DC calculation wizard is only available when operating via the local display. When operating via an operating tool, all parameters concerning the automatic DC calculation are located directly in the Interface submenu (→  144) In the Automatic DC calculation wizard two parameters are displayed simultaneously on the display module at any one time.
Page 151 Levelflex FMP55 FOUNDATION Fieldbus Operating menu "Linearization" submenu 100% L‘ I‘ L‘ 100% L‘1L‘2 L‘ 100% L‘ 100% L‘ 100% L‘ 100% L‘ 100% L‘ A0016084  31 Linearization: Transformation of the level and (if relevant) the interface height into a volume or weight;...
Page 152 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Structure of the submenu on the display module Navigation  Setup → Advanced setup → Linearization ‣ Linearization Linearization type →  154 Unit after linearization →  155 Free text →  156 Maximum value →...
Page 153 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Structure of the submenu in an operating tool (e.g. FieldCare) Navigation  Setup → Advanced setup → Linearization ‣ Linearization Linearization type →  154 Unit after linearization →  155 Free text →  156 Level linearized →...
Page 154 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Description of parameters Navigation  Setup → Advanced setup → Linearization Linearization type  Navigation  Setup → Advanced setup → Linearization → Lineariz. type Description Select linearization type. Selection • None • Linear •...
Page 155 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Meaning of the options • None The level is transmitted in the level unit without linearization. • Linear The output value (volume/weight) is directly proportional to the level L. This is valid, for example, for vertical cylinders. The following additional parameters have to be specified: –...
Page 156 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Selection SI units US units Imperial units • STon • lb impGal • t • UsGal • kg • ft³ • cm³ • dm³ • m³ • hl • l • % Custom-specific units...
Page 157 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Interface linearized Navigation  Setup → Advanced setup → Linearization → Interf. lineariz Prerequisite Operating mode (→  129) = Interface or Interface with capacitance Description Displays the linearized interface height. Additional information The unit is defined in the Unit after linearization parameter →  155.
Page 158 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Intermediate height  Navigation  Setup → Advanced setup → Linearization → Intermed. height Prerequisite Linearization type (→  154) has one of the following values: • Pyramid bottom • Conical bottom • Angled bottom Description Specify intermediate height H.
Page 159 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Additional information Meaning of the options • Manual The level and the associated linearized value are entered manually for each linearization point. • Semiautomatic The level is measured by the device for each linearization point. The associated linearized value is entered manually.
Page 160 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Level (Manual)  Navigation  Setup → Advanced setup → Linearization → Level Prerequisite • Linearization type (→  154) = Table • Table mode (→  158) = Manual Description Enter level value of the table point (value before linearization).
Page 161 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Factory setting Disable Additional information Meaning of the options • Disable The measured level is not linearized. If Linearization type (→  154) = Table at the same time, the device issues error message F435.
Page 162 Operating menu Levelflex FMP55 FOUNDATION Fieldbus "Safety settings" submenu Navigation  Setup → Advanced setup → Safety sett. Output echo lost  Navigation  Setup → Advanced setup → Safety sett. → Output echo lost Description Define the behavior of the output signal in case of a lost echo.
Page 163 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Ramp at echo lost  Navigation  Setup → Advanced setup → Safety sett. → Ramp echo lost Prerequisite Output echo lost (→  162) = Ramp at echo lost Description Define the slope of the ramp in the case of a lost echo.
Page 164 Operating menu Levelflex FMP55 FOUNDATION Fieldbus due to a level change during operation. Signals which are already in the blocking distance when the device is switched on, are ignored. This behavior is only valid if the following two conditions are met: •...
Page 165 Levelflex FMP55 FOUNDATION Fieldbus Operating menu "Probe settings" submenu The Probe settings submenu helps to ensure that the end of probe signal within the envelope curve is correctly assigned by the evaluation algorithm. The assignment is correct if the length of probe indicated by the device matches the acutal lenght of the probe. The automatic probe length correction can only be performed if the probe is installed in the vessel and is completely uncovered (no medium).
Page 166 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Confirm probe length  Navigation  Setup → Advanced setup → Probe settings → Confirm length Description Select, whether the value displayed in the Present probe length parameter →  165 matches the actual length of the probe. Based on this input, the device performs a probe length correction.
Page 167 Levelflex FMP55 FOUNDATION Fieldbus Operating menu "Probe length correction" wizard The Probe length correction wizard is only available when operating via the local display. When operating via an operating tool, all parameters concerning the probe length correction are located directly in the Probe settings submenu (→  165).
Page 168 Operating menu Levelflex FMP55 FOUNDATION Fieldbus "Switch output" submenu Navigation  Setup → Advanced setup → Switch output Switch output function  Navigation  Setup → Advanced setup → Switch output → Switch out funct Description Select function for switch output.
Page 169 Levelflex FMP55 FOUNDATION Fieldbus Operating menu • Digital output 2 • Digital output 3 • Digital output 4 • Digital output 5 • Digital output 6 • Digital output 7 • Digital output 8 Factory setting Additional information The Digital output AD 1 and Digital output AD 2 options refer to the Advanced Diagnostic Blocks.
Page 170 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Selection • Alarm • Alarm or warning • Warning Factory setting Alarm Switch-on value  Navigation  Setup → Advanced setup → Switch output → Switch-on value Prerequisite Switch output function (→  168) = Limit Description Enter measured value for the switch-on point.
Page 171 Levelflex FMP55 FOUNDATION Fieldbus Operating menu A0015586 Switch-on value Switch-off value Output closed (conductive) Output opened (non-conductive) Switch-on delay  Navigation  Setup → Advanced setup → Switch output → Switch-on delay Prerequisite • Switch output function (→  168) = Limit •...
Page 172 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Switch-off delay  Navigation  Setup → Advanced setup → Switch output → Switch-off delay Prerequisite • Switch output function (→  168) = Limit • Assign limit (→  169) ≠ Off Description Define switch-off delay.
Page 173 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Additional information Meaning of the options • No The behavior of the switch output is as described above. • Yes The states Open and Closed are inverted as compared to the description above. Endress+Hauser...
Page 174 Operating menu Levelflex FMP55 FOUNDATION Fieldbus "Display" submenu The Display submenu is only visible if a display module is connected to the device. Navigation  Setup → Advanced setup → Display Language Navigation  Setup → Advanced setup → Display → Language Description Set display language.
Page 175 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Additional information 4841.000 Â A0019963  34 "Format display" = "1 value, max. size" Â 93.5 % Â 159.0 A0019964  35 "Format display" = "1 bargraph + 1 value" Â 93.5 Â 159.0 A0019965 ...
Page 176 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Value 1 to 4 display  Navigation  Setup → Advanced setup → Display → Value 1 display Description Select the measured value that is shown on the local display. Selection • None • Level linearized •...
Page 177 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Display interval Navigation  Setup → Advanced setup → Display → Display interval Description Set time measured values are shown on display if display alternates between values. User entry 1 to 10 s Factory setting...
Page 178 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Header text  Navigation  Setup → Advanced setup → Display → Header text Prerequisite Header (→  177) = Free text Description Enter display header text. Factory setting ------------ Additional information The number of characters which can be displayed depends on the characters used.
Page 179 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Selection • x • x.x • x.xx • x.xxx • x.xxxx Factory setting x.xxxx Additional information • Is only valid for numbers in the operating menu (e.g. Empty calibration, Full calibration), but not for the measured value display. The number of decimal places for the measured value display is defined in the Decimal places 1 to 4 →...
Page 180 Operating menu Levelflex FMP55 FOUNDATION Fieldbus "Configuration backup display" submenu This submenu is only visible if a display module is connected to the device. The configuration of the device can be saved to the display module at a certain point of time (backup).
Page 181 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Additional information Meaning of the options • Cancel No action is executed and the user exits the parameter. • Execute backup A backup copy of the current device configuration in the HistoROM (built-in in the device) is saved to the display module of the device.
Page 182 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Additional information Meaning of the display options • Settings identical The current device configuration of the HistoROM is identical to the backup copy in the display module. • Settings not identical The current device configuration of the HistoROM is not identical to the backup copy in the display module.
Page 183 Enter access code parameter (→  143). Please contact your Endress+Hauser Sales Center if you lose your access code. For display operation: The new access code is only valid after it has been confirmed in the Confirm access code parameter (→...
Page 184 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Additional information Meaning of the options • Cancel No action • To factory defaults All parameters are reset to the order-code specific factory setting. • To delivery settings All parameters are reset to the delivery setting. The delivery setting may differ from the factory default if customer specific settings have been ordered.
Page 185 Levelflex FMP55 FOUNDATION Fieldbus Operating menu "Define access code" wizard The Define access code wizard is only available when operating via the local display. When operating via an operating tool, the Define access code parameter is located directly in the Administration submenu. The Confirm access code parameter is not available for operation via operating tool.
Page 186: Diagnostics" Menu
Operating menu Levelflex FMP55 FOUNDATION Fieldbus 17.4 "Diagnostics" menu Navigation  Diagnostics Actual diagnostics Navigation  Diagnostics → Actual diagnos. Description Displays current diagnostic message. Additional information The display consists of: • Symbol for event behavior • Code for diagnostic behavior •...
Page 187 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Timestamp Navigation  Diagnostics → Timestamp Description Displays timestamp for the Previous diagnostics parameter (→  186). User interface Days (d), hours (h), minutes (m), seconds (s) Operating time from restart Navigation  Diagnostics → Time fr. restart Description Displays the time the device has been in operation since the last device restart.
Page 188: Diagnostic List" Submenu
Operating menu Levelflex FMP55 FOUNDATION Fieldbus 17.4.1 "Diagnostic list" submenu Navigation  Diagnostics → Diagnostic list Diagnostics 1 to 5 Navigation  Diagnostics → Diagnostic list → Diagnostics 1 to 5 Description Display the current diagnostics messages with the highest to fifth-highest priority.
Page 189: Event Logbook" Submenu
Levelflex FMP55 FOUNDATION Fieldbus Operating menu 17.4.2 "Event logbook" submenu The Event logbook submenu is only available when operating via the local display. When operating via FieldCare, the event list can be displayed in the FieldCare function "Event List / HistoROM".
Page 190: Device Information" Submenu
Displays serial number of the device. Additional information Uses of the serial number • To identify the device quickly, e.g. when contacting Endress+Hauser. • To obtain specific information on the device using the Device Viewer: www.endress.com/deviceviewer The serial number is also indicated on the nameplate.
Page 191 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Order code  Navigation  Diagnostics → Device info → Order code Description Displays order code of the device. Additional information The order code is generated from the extended roder code, which defines all device features of the product structure.
Page 192: Measured Values" Submenu
Operating menu Levelflex FMP55 FOUNDATION Fieldbus 17.4.4 "Measured values" submenu Navigation  Diagnostics → Measured val. Distance Navigation  Diagnostics → Measured val. → Distance Description Displays the measured distance D between the reference point (lower edge of the flange or threaded connection) and the level.
Page 193 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Description Displays the measured distance D between the reference point (lower edge of flange or threaded connection) and the interface. Additional information A0013202 The unit is defined in the Distance unit parameter (→  129).
Page 194: Analog Input 1 To 5" Submenu
Operating menu Levelflex FMP55 FOUNDATION Fieldbus Additional information A0013313 UP Thickness upper layer The unit is defined by the Unit after linearization parameter →  155. Terminal voltage 1 Navigation  Diagnostics → Measured val. → Terminal volt. 1 Description Dipslays terminal voltage at the current output.
Page 195 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Channel Navigation  Diagnostics → Analog inputs → Analog input 1 to 7 → Channel Description Select the process variable. Selection • Uninitialized • Level linearized • Absolute echo amplitude • Absolute EOP amplitude •...
Page 196 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Units index Navigation  Diagnostics → Analog inputs → Analog input 1 to 7 → Units index Description Indicates the unit of the output value. Endress+Hauser...
Page 197: Data Logging" Submenu
Levelflex FMP55 FOUNDATION Fieldbus Operating menu 17.4.6 "Data logging" submenu Navigation  Diagnostics → Data logging Assign channel 1 to 4  Navigation  Diagnostics → Data logging → Assign chan. 1 to 4 Description Allocate a process variable to the respective data logging channel.
Page 198 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Logging interval  Navigation  Diagnostics → Data logging → Logging interval Description Define logging interval t User entry 1.0 to 3 600.0 s Factory setting 30.0 s Additional information This parameter defines the interval between the individual data points in the data log, and thus the maximum loggable process time T •...
Page 199 Levelflex FMP55 FOUNDATION Fieldbus Operating menu "Display channel 1 to 4" submenu The Display channel 1 to 4 submenus are only available for operation via the local display. When operating via FieldCare, the logging diagram can be displayed in the FieldCare function "Event List / HistoROM"...
Page 200: Simulation" Submenu
Operating menu Levelflex FMP55 FOUNDATION Fieldbus 17.4.7 "Simulation" submenu The Simulation submenu is used to simulate specific measuring values or other conditions. This helps to check the correct configuration of the device and connected control units. Conditions which can be simulated...
Page 201 Levelflex FMP55 FOUNDATION Fieldbus Operating menu 3. Pull out the display module with a gentle rotation movement. To make it easier to access the SIM switch, attach the display module to the edge of the electronics compartment.  Display module is attached to the edge of the electronics compartment.
Page 202 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Structure of the submenu Navigation  Expert → Diagnostics → Simulation ‣ Simulation Assign measurement variable →  203 Process variable value →  203 Switch output simulation →  203 Switch status →  204 Simulation device alarm →...
Page 203 Levelflex FMP55 FOUNDATION Fieldbus Operating menu Description of parameters Navigation  Expert → Diagnostics → Simulation Assign measurement variable  Navigation  Expert → Diagnostics → Simulation → Assign meas.var. Description Selct process variable to be simulated. Selection • Off •...
Page 204 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Selection • Off • On Factory setting Switch status  Navigation  Expert → Diagnostics → Simulation → Switch status Prerequisite Switch output simulation (→  203) = On Description Define the switch state to be simulated.
Page 205: Device Check" Submenu
Levelflex FMP55 FOUNDATION Fieldbus Operating menu 17.4.8 "Device check" submenu Navigation  Diagnostics → Device check Start device check  Navigation  Diagnostics → Device check → Start dev. check Description Start a device check. Selection • No • Yes...
Page 206 Operating menu Levelflex FMP55 FOUNDATION Fieldbus Level signal Navigation  Diagnostics → Device check → Level signal Prerequisite Device check has been performed. Description Displays result of the device check for the level signal. User interface • Check not done •...
Page 207: Heartbeat" Submenu
Levelflex FMP55 FOUNDATION Fieldbus Operating menu 17.4.9 "Heartbeat" submenu The Heartbeat submenu is only available via FieldCare or DeviceCare. It contains the wizards which are part of the Heartbeat Verification and Heartbeat Monitoring application packages. Detailed description SD01872F Navigation  Diagnostics → Heartbeat...
Page 208: Index
Data logging (Submenu) ..... 197 Enable simulation ......200 Endress+Hauser...
Page 209 Level linearized (Parameter) ....156, 192 Registered trademarks ......17 Endress+Hauser...
Page 210 Interface ......144 Write protection switch ..... . . 51 Endress+Hauser...
Page 212 *71344076* 71344076 www.addresses.endress.com...

Endress+Hauser Levelflex FMP55 Operating Instructions Manual

1 Important Document Information

2 Basic Safety Instructions

3 Product Description

4 Incoming Acceptance and Product

Identification

5 Storage, Transport

6 Mounting

7 Electrical Connection

8 Operation Options

9 Integration into a FOUNDATION

Fieldbus Network

10 Commissioning Via Wizard

11 Commissioning Via Operating

Menu

12 Commissioning

Operation)

13 Diagnostics and Troubleshooting

14 Maintenance

15 Repairs

16 Accessories

17 Operating Menu

Index

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Endress+Hauser Levelflex FMP55

Summary of Contents for Endress+Hauser Levelflex FMP55

Table of Contents
