Levelflex FMP55 FOUNDATION Fieldbus
Distance
Navigation
Description
Additional information
Level linearized
Navigation
Description
Additional information
Interface distance
Navigation
Prerequisite
Endress+Hauser
17.4.4

"Measured values" submenu

Navigation  Diagnostics → Measured val.
 Diagnostics → Measured val. → Distance
Displays the measured distance D
or threaded connection) and the level.
 45 Distance for interface measurements
The unit is defined in the Distance unit parameter (→  126).
 Diagnostics → Measured val. → Level linearized
Displays linearized level.
• The unit is defined by the Unit after linearization parameter →  152.
• For interface measurements, this parameter always refers to the total level.
 Diagnostics → Measured val. → Interface dist.
Operating mode (→  126) = Interface or Interface with capacitance
between the reference point (lower edge of the flange
L
D
L
D
Operating menu
L
A0013199
189
