 27 The "Fail Map" and "Check Map" columns after the change
Please ensure that the corresponding bit is set in at least one of the assignment
parameters for each event group. Otherwise no category will be transmitted with the
event over the bus, and the control system will therefore generally ignore the
presence of the event.
The detection of diagnostic events is parameterized on the Alarm detection enable
FieldCare page but the transmission of messages over the bus is not. The latter is
performed on the Alarm broadcast enable page. The operation of this page is
identical to the operation of the Alarm detection enable page. The Resource Block
must be in the Auto mode for the status information to be transmitted over the bus.
