Installation
Overview
1.
2.
3.
4.
Before starting, download and install the latest versions of the following software:
GUI Designer — for designing layouts for Extron TouchLink Pro touchpanels and
third party touch interfaces.
Global Configurator Plus and Professional — for setting up and configuring the
control processor and touchpanel.
Toolbelt — provides device discovery, device information, firmware updates,
and configuration of network settings, system utilities, and user management for
TouchLink Pro devices.
See Configuration Software
Obtain the following network information from your network administrator:
DHCP status (on or off). If DHCP is off, you will also require
IP address
Subnet mask
Gateway
User name — by default, these are either
Passwords — by default, these are either extron (for admin) or the field is left blank
(for user).
MAC address — make a note of the touchpanel MAC address.
Prepare to mount the Cable Cubby:
Make sure you are familiar with all the
necessary tools (see page 7) for installing the cable cubby.
Plan where you are going to install the Cable Cubby and how you are going to cut the
hole.
Ensure the TLP Pro 320C is oriented correctly and that there is adequate room for
cables and cable retractors (optional).
Ensure you are using the correct cut-out template or dimensions (see
Dimensions on page 8).
Ensure the installation complies with all necessary regulations.
Mount the Cable Cubby:
Cut the table surface (see
Run all cables to the unit (see
Install cable retractors (optional) (see
Install the power module (optional) (see
Put together and install the AAP assembly (see
Assemblies on page 12).
Mount the Cable Cubby (see
on page 30.
admin or user
included parts (see page 7) and have all the
Cutting the Table on page 8).
Running Cables on page 10).
Installing Cable Retractors
Installing Power Modules
Preparing and Installing the AAP
Mounting the TLP Pro 320C Enclosure
TLP Pro 320C • Installation Overview
.
Cut-out
on page 10).
on page 11).
on page 14).
4
