Extron electronics TouchLink TLP Pro 320C User Manual page 22

Figure 9 Figure 11
C C
Figure 11.
With the lid down, the ambient light sensor (figure 11,
illumination LED (
A
B
C
D
E
F
G
H
I
J
K
A A B B
TLP Pro 320C Front Panel with Bezel Removed
J , below right) are disabled. All three are activated by opening the lid.
Communication LED — shows the touchpanel configuration and connection status:
•
Unlit during normal operation (the touchpanel is configured and connected to an
IP Link Pro control processor).
•
Blinks red if the touchpanel has been configured but is not connected to an IP Link
Pro control processor.
•
Permanently lit if the touchpanel has not been configured.
The LED can be toggled between enabled and disabled (see
Ambient light sensor — monitors ambient light level and adjusts screen brightness,
based on the settings configured using the setup menu
LCD screen — the TLP Pro 320C has a 3.5 inch screen with a 320x240 resolution.
Configurable buttons — 10 dedicated, customizable, function buttons provide quick
access to key functions.
Reset LED— indicates power status and reset status of the device.
Reset button — this button allows the unit to
be reset. The TLP Pro 320C has three reset
modes that are initiated by pressing the reset
button (see Reset Modes on page 36).
Menu button — activates the
page 21) and calibration screen
Bezel — use the included removal tool to
detach the bezel.
Bezel removal slots — for removing bezel,
using Extron removal tool (see
page 15).
Illumination LED — provides light for cable
cubby enclosure.
Speaker — one, placed inside the cable cubby,
provides audible feedback for the user.
E E F F G G
), the LCD screen (
B
Display screen
setup menu (see
(see page 29).
figure 10 on
TLP Pro 320C • Panel Features
D D
), and
C
setup menu on page 21).
(see page 26).
I I
H H
D D
J J
K K
