Network Screen

The image below shows the entire
can only see part of the screen at any time. Flick the touchscreen with your finger to navigate
up or down within the screen.
Figure 17.
The Domain Name (optional) and MAC Address are read-only.
Verify with your network administrator whether the network settings for the touchpanel are
assigned by Dynamic Host Configuration Protocol (DHCP) or set manually. If they are set
manually, obtain an IP address, a subnet mask, a gateway address, and a Domain Name
Server (DNS) IP address from the network administrator.
1.
Network
NETWORK SETTINGS
DHCP:
Hostname: TLP-Pro-320C-AB-CD-EF
IP Address:
Subnet Mask:
Gateway:
DNS Server:
Domain Name:
MAC Address: 00-05-A6-AB-CD-EF
Network Screen
If IP addresses are assigned manually, press the
When the slider is off, the
values can all be edited (they are shown on a gray button that can be
Server
pressed). There is an arrowhead beside each button.
If IP addresses are assigned by DHCP, Press the
When the slider is on, the
Server values cannot be edited (they are shown in white text, with no button and no
arrowhead). Only the
Host Name
screen. Because of size of the touchscreen, you
Network
Revert Apply Exit
X
192.168.254.251
255.255.255.0
0.0.0.0
127.0.0.1
DHCP
IP Address , Subnet Mask
DHCP
,
IP Address Subnet Mask
can be edited.
TLP Pro 320C • Setup Menu
slider to the position.
Off
, Gateway , and DNS
slider to the position.
On
, , and
Gateway DNS
