Application Diagram

This diagram shows a typical application for the TLP Pro 320C touchpanel.
Extron
DTP HDMI 330 Rx
Receiver
Figure 1.

Requirements

Software

For a complete list of the requirements for running GUI Designer, Global Configurator Plus and
Professional, or Toolbelt, see the Extron Web page for the appropriate software.
NOTE:

Hardware

An Extron IP Link Pro control interface must also be connected to the same network domain
as the TouchLink panel. See
NOTE: These touchpanels are not compatible with Extron IP Link (non-Pro) controllers.
SIG LINK
POWER
12V
0.7A MAX
DTP IN
Laptop
Extron
TLP Pro 320C
3.5" Cable Cubby
TouchLink Pro
Touchpanel
COM 1 COM 2 DIGITAL I/O
IPCP PRO 250 Extron
Tx Rx G RTS CTS Tx Rx G 1 2 3 4 G
POWER IPCP Pro 250
VOL RELAYS eBUS IR/S
12V
--A MAX V C G 1 2 C
+V +S - S G
PWR OUT = 6W S G LAN IP Link Pro
Control
Processor
Ethernet
Application Diagram
The TLP Pro 320C is not compatible with Global Configurator 3 or
GUI Configurator.
www.extron.com
RS-232
MODEL 80
OVER DTP
RS-232 IR
Tx Rx G Tx Rx
DTP HDMI 330 Rx
OUTPUTS
AUDIO
L R
HDMI
Flat Panel Display
Ethernet HDMI
LAPTOP DISPLAY ON
DVD Combined Combined
PC DISPLAY OFF
DVD MUTE
DOC CAM VOLUME
More Video
AUXILIARY VOLUME
RS-232
Ethernet/PoE
TCP/IP
Network
for a list of suitable controllers.
TLP Pro 320C • Introduction
FLAT PANEL
CATx Cable
up to 330'
(100 m)
INPUTS SIG LINK OVER DTP
POWER
AUDIO
12V
RS-232 IR
0.7A MAX
Tx Rx G Tx Rx
DTP OUT
Extron
DTP HDMI
330 Tx
Transmitter
HDMI
