Reset All IP Settings

Purpose
Reset All IP Settings mode enables you to reset IP settings and port maps to factory defaults.
Activation
To reset all IP settings:
1.
Hold down the
at 3 seconds, again at 6 seconds).
2.
Release and press
happens if the momentary press does not occur within 1 second.
Result
Reset All IP Settings mode:
•
Sets the IP address back to factory default (192.168.254.251)
•
Sets the subnet back to factory default (255.255.255.0)
• Sets the default gateway address to the factory default (0.0.0.0)
• Sets all other IP settings, addresses, and domain and host names back to factory default.
• Turns DHCP off.

Reset to Factory Defaults

Purpose
This mode is useful if you want to start over with configuration and uploading.
Activation
To reset the unit to all factory default settings:
1.
Hold down the
(once at 3 seconds, again at 6 seconds, again at 9 seconds).
2.
Release and press
happens if the momentary press does not occur within 1 second.
Result
Reset to Factory Defaults mode performs a complete reset to factory defaults (except the
firmware).
• Does everything Reset All IP Settings mode does.
•
Removes touchpanel configurations and user interface.
button for about 6 seconds until the Reset LED blinks twice (once
Reset
Reset momentarily (for less than 1 second) within 1 second. Nothing
Reset button for about 9 seconds until the Reset LED blinks three times
Reset momentarily (for less than 1 second) within 1 second. Nothing
TLP Pro 320C • Reference Material 37
