Using the Software
Use the appropriate software help file for step-by-step instructions and more detailed
information. The Global Configurator Help File also includes an introduction to the software and
sections on how to start and configure a project.
GUI Designer
Use the GUI Designer software to design the screen layout for the touchpanel. See the
GUI Designer Help File for step-by-step instructions and more detailed information.
Global Configurator Plus and Professional
Use the Global Configurator software to set up and configure the control processor and the
touchpanel. See the Global Configurator Help File for step-by-step instructions and more
detailed information. The Global Configurator Help File also includes an introduction to the
software and sections on how to start and configure a project.
Toolbelt
Use the Toolbelt software for device discovery, device information, firmware updates, and
configuration of network settings, system utilities, and user management for TouchLink Pro
devices.
TLP Pro 320C Web Page
To access the touchpanel default Web pages, enter the IP address of the unit into the Web
browser of a PC connected to the same subnet. There is a single, read-only page that
provides general and network information about the unit (see figure 26, below). It also allows
you to upgrade the unit firmware.
A dialog opens asking for your user name and password. By default, the user name is
admin
and the password is
extron
(both user name and password are all lower case).
The single page provides general and network information about the unit. It also allows you
to upgrade the unit firmware. This page cannot be used to configure the touchpanel network
settings. To configure those settings, use the
Setup Menu
(see page 21) or the Toolbelt
feature of Global Configurator.
Figure 26.
TLP Pro 320C Web Page
Click the License Information button to view details about third-party packages and associated
licensing (and see
Licensed Third-Party Software Used in the Touchpanels
on page 39).
TLP Pro 320C • Configuration Software
32
