Connectors

The cable connections are located in a panel on the bottom of the TLP Pro 320C:
A A
B B
Figure 12.
The TLP Pro 320C can use a 12 VDC desktop power supply and is also Power over Ethernet
(PoE 802.3af, class 3) compliant.
NOTE:
Extron recommends that you use the following power sources:
•
•
ATTENTION:

Power Connector

Connect a 12 VDC, 1.0 A power supply (not provided) to this 2-pole, 3.5 mm captive screw
connector. Ensure the connections have the correct polarity as shown below.
Power Receptacle
POWER
12V
1.0 A MAX
Figure 13.
Cable Connectors for TLP Pro 320C
The TLP Pro 320C ships without a power supply. Either the 12 VDC power
supply or the PoE injector must be purchased separately.
12 VDC — PS 1210C power supply (part number 70-775-01).
Power over Ethernet — XTP PI 100 power injector (part number 60-1233-01).
•
Do not power on the touchpanels or control processors until you have read the
Attention notice on page 18
•
Ne branchez pas les écrans tactiles ou les contrôleurs avant d'avoir lu les mises en
garde page 18 (source d'alimentation 12 VCC) ou
DC Power Cord
Captive Screw Connector
Ground
+12 VDC
Power Supply
(12 VDC, 1 A )
AC Power Cord
Power Supply Connection
(12 VDC power supply) or on
page 20
Smooth
A
Power Supply
Output Cord
SECTION A–A
External
TLP Pro 320C • Panel Features
Power Connector
A
LAN/PoE
B
page 20 (PoE injector).
(injecteur PoE).
-
Ridges
A
POWER
12V
1.0 A MAX
3/16"
-
(5 mm) Max.
-
17
