5.
Connect cables to the touchpanel. The unit can be powered using a 12 VDC power
supply or a Power over Ethernet (PoE) power injector.
If required, connect the power supply (see
Connect the network cable (see
page 19).
ATTENTION:
• Do not power on the touchpanels or control processors until you have
read the Attention notice on
page 20 (PoE injector).
• Ne branchez pas les écrans tactiles ou les contrôleurs avant d'avoir lu
les mises en garde
(injecteur PoE).
6. Set up the TLP Pro 320C for Network Communication:
Connect the PC that you will use for setup, the control processor, and the touchpanel
to the same Ethernet subnetwork.
Use the Setup Menu
and Professional to set the DHCP status and, if necessary, the IP address, subnet
mask, gateway, and related settings for the touchpanel.
7.
Configure the TLP Pro 320C — the GUI Designer Help File, the Global Configurator Help
File, and the Toolbelt Help File, provide step-by-step instructions and detailed information.
The Global Configurator Help File also includes an introduction to that software and
sections on how to start a project and configuration.
Power Connector
Network and Power over Ethernet Connector
page 18 (12 VDC power supply) or on
page 18 (source d'alimentation 12 VCC) ou
(see page 21) or the Toolbelt feature of Global Configurator Plus
TLP Pro 320C • Installation Overview
on page 17).
on
page 20
