● Store a replaceable unit in the antistatic bag and the specially designed shipping container in which you received it. Use the
antistatic bag and special shipping container when you need to return the replaceable unit.
● Replaceable units must acclimate to the operating environment before applying power. This requires the unpackaged
component to reside in the operating environment for up to 16 hours in order to thermally stabilize and prevent
condensation. Refer to
environment.
NOTE:
Your storage system is designed to be powered on continuously. Most components are hot swappable; that is, you
can replace or install these components while the storage system is running. However, the system requires that front bezels
should always be attached to ensure EMI compliance. Make sure you reattach the bezel after replacing a component. Also,
each slot should contain a component or filler panel to ensure proper air flow throughout the system.
Unpacking a part
Use these best practices to unpack a part.
Steps
1. Wear ESD gloves or attach an ESD wristband to your wrist and the enclosure in which you are installing the part.
2. Unpack the part and place it on a static-free surface.
3. If the part is a replacement for a faulted part, save the packing material to return the faulted part.
Standard touch point colors
Touch points are component locations where you can:
● Grip the hardware to remove or install a component.
● Open or close a latch.
● Turn a knob to open, close, or adjust a component.
Standard touch point colors are terra-cotta (orange) or blue.
NOTE:
Within this documentation, the color orange is used instead of terra-cotta for simplicity.
Table 11. Standard touch point colors
Touch point color
Terra-cotta
(orange)
Blue
Hardware acclimation times
Description
This color indicates that you can perform the task, such as remove a component with a terra-
cotta (orange) lever, while the system remains powered (up/on).
NOTE:
Some tasks may require additional steps.
This color indicates that a shutdown of the system or component is required before you can
perform the task, such as removing a component with a blue lever.
to ensure the replaceable unit has thermally stabilized to the operating
Safety precautions for handling replaceable units
107
