ACCESSING:
DESCRIPTION: This screen is used to log certain messages and events that are generated through normal unit opera-
tion. Occurrences such as normal power up and power down sequences, as well as all maintenance schedule mes-
sages (see the Maintenance screen for more information on these messages).
The messages that appear on this screen cannot be
cleared, they will be stored indefi nitely.
The user can use the arrow keys on the keypad to scroll
down through the list.
The left side of this screen is numbered for each event
which has occurred. Under the Event heading, the specifi c
event will be shown that caused a normal system event. In
this case, Software Maintenance was performed at row 3.
QUANTUM™ LX COMPRESSOR CONTROL PANEL
OPERATION
SYSTEM STATUS - Event Log
System Status...

Event Log

The next column shows each time the control panel was
powered down or powered up. This includes all cycling of
power, whether intentional or not (a power failure will be
shown as a power down/power up event).
The fi nal column at the right side of the screen shows
the date and the time of the event. It is very important
to ensure that the correct Date and Time are set, so that
accurate event logging can be maintained.
