ACCESSING:
DESCRIPTION: This screen allows for monitoring of the Kilowatt hours that have been used by the compressor.
This screen provides the Kilowatt hours that the compres-
sor has used since the date in the Figures Are Since row.
Tabbing to the reset button will reset the Kilowatt hours
QUANTUM™ LX COMPRESSOR CONTROL PANEL
OPERATION
SYSTEM STATUS – kWh Monitoring
System Status...

kWh Monitoring

to 0 and will set the date beside the reset button to the
current date.
090.022-O (MAY 12)
Page 29
