© 1994 Johnson Controls, Inc.
Order No. 406-020
All manuals and user guides at all-guides.com
Installing the FC-2000
FC-2000 Technical Manual 406
Installation Section
Technical Bulletin
Issue Date 0794
Page
3
3
4
4
5
6
6
9
10
12
15
16
19
21
22
23
26
27
28
29
31
32
33
34
35
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FC-2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Johnson Controls FC-2000

Summary of Contents for Johnson Controls FC-2000

  • Page 1: Table Of Contents

    All manuals and user guides at all-guides.com FC-2000 Technical Manual 406 Installation Section Technical Bulletin Issue Date 0794 Installing the FC-2000 Introduction Page Description Key Features Minimum System Configurations NFPA Standards UL Documents Other Standards and Documents Installation Installation Outline...
  • Page 2 Remote Presignal Inhibit, All Call (General Alarm), Emergency Alert, Acknowledge, Signal Silence, and System Reset Switches Telephone Paging Testing the System Acceptance Test Periodic Testing and Service Operational Checks Battery Checks and Maintenance Calculating Power Supply Requirements AC Branch Circuit Main Power Supply 2 Installation—Installing the FC-2000...

  • Page 3: Introduction

    All manuals and user guides at all-guides.com Introduction The FC-2000 is an expandable multi-zone Fire Alarm Control Panel Description designed with maximum flexibility and modularity as a basic requirement. The heart of the system is the Central Processor Unit (CPU-2000) module, which monitors and directs the actions of all other modules in the system.

  • Page 4: Key Features

    Plug-in terminal blocks for ease of field wiring Walk test any portion of system while remainder provides fire protection Liquid crystal display and printer options The following FC-2000 components are required for compliance with Minimum NFPA standards 71 and 72: System Configurations 1.

  • Page 5: Nfpa Standards

    Remote Station, and Proprietary Protective Signaling Systems NFPA 72 Emergency Voice Alarm Service NFPA 72 Automatic Fire Detectors NFPA 72 Installation, Maintenance, and Use of Indicating Appliances for Protective Signaling Systems NFPA 72 Testing Procedures for Signaling Systems Installation—Installing the FC-2000...

  • Page 6: Ul Documents

    NEC Article 300 Wiring Methods NEC Article 760 Fire Protective Signaling Systems In addition, you must adhere to the standards of the applicable local and state building codes and requirements of the local Authority Having Jurisdiction (AHJ). 6 Installation—Installing the FC-2000...
  • Page 7 ARM-4 VCE-4, CRE-4 or ICE-A CRE-4 CRM-4 ICM-4 TCM-2 TCM-4 VCM-4 AVPS-24 AVPS-24 configop Figure 1: Physical Configuration Options Note: The ARM-4 must be mounted under or in a position adjacent to its associated CRM-4 or CRE-4. Installation—Installing the FC-2000...
  • Page 8 All manuals and user guides at all-guides.com 8 Installation—Installing the FC-2000...

  • Page 9: Installation

    All manuals and user guides at all-guides.com Installation Modules in the system communicate with the CPU through a common ribbon cable connection. aim200up Figure 2: Module Connection Example Installation—Installing the FC-2000...

  • Page 10: Installation Outline

    All manuals and user guides at all-guides.com The following procedure outlines the installation and field wiring of the Installation FC-2000’s modules and refers to illustrations in the Installation, Field Outline Wiring the Modules, and Power Supplies sections of this document. This procedure, and its diagrams and instructions, must be followed closely to avoid damage to the control panel and its associated equipment.
  • Page 11 TCM-2 and TCM-4: Refer to those documents in this manual. VCM-4/VCE-4, DCM-4, AMG-1, FFT-7: For installation and field wiring of voice alarm equipment, refer to the FC-2000 Fire Fighter’s Command Center Technical Bulletin in this manual. 13. Power-on-check--Apply AC power to the system. Do not connect the batteries at this time! To silence the audible trouble sounder, push the ACKNOWLEDGE switch on the CPU.

  • Page 12: Cabinet Installation

    All manuals and user guides at all-guides.com 14. Programming--To configure and program the system for operation, refer to the Programming the FC-2000 Technical Bulletin in this manual. 15. Batteries--Once the system has been programmed and is functional, connect the batteries. Ensure that all indicators except AC POWER are extinguished.
  • Page 13 5/16 dia. 2-9/16 19-1/2 2-1/4 C A B -A 3 24-1/8 5-5/32 2-1/16 1-5/8 8-5/8 19-25/32 8-5/8 28-1/2 28-5/8 5/16 dia. C A B -B 3 2-9/16 19-1/2 2-1/4 cab-x3b1 Figure 4: CAB-A3 and CAB-B3 Cabinets (inches) Installation—Installing the FC-2000...
  • Page 14 C A B -C 3 2-9/16 19-1/2 2-1/4 24-1/8 5-5/32 2-1/16 1-5/8 8-5/8 8-5/8 8-5/8 37-1/32 45-3/4 45-7/8 8-5/8 5/16 dia. 2-9/16 C A B -D 3 19-1/2 2-1/4 cab-x3b Figure 5: CAB-C3 and CAB-D3 Cabinets (inches) 14 Installation—Installing the FC-2000...

  • Page 15: Trim Ring For Cab-X3 Enclosures

    Note: The side trim ring pieces should have the holes nearest to the edge facing outward. See Figure 6. TR-A3 = 19-5/8 in. TR-B3 = 28-1/8 in. TR-C3 = 36-3/4 in. TR-D3 = 45-3/8 in. trimring Figure 6: Trim Ring Installation Installation—Installing the FC-2000...

  • Page 16: Cab-X3 Door Assembly

    Figure 7: Mounting the CAB-x3 Cabinet Door IMPORTANT: Assemble the two hinges and two alignment tabs to the backbox before you install any equipment. Installing the chassis severely limits space in the areas where the hinges and alignment tabs are installed. 16 Installation—Installing the FC-2000...
  • Page 17 Place the grounding “star” washer on the stud. Place the door’s lower corner onto this stud. Placing the door on the lower stud first provides a place for the door to rest while you complete the assembly, as shown above. Installation—Installing the FC-2000...
  • Page 18 PEM stud with the nut provided. These tabs align the door correctly with the backbox and prevent the door from being “skewed” open. Right Corner Door Alignment Tab Door Alignment Tab cabx3aa3 Bottom Right Corner Figure 10: Door Alignment Tabs 18 Installation—Installing the FC-2000...

  • Page 19: Installing The Chs-4 Chassis

    1. Place the CHS-4 over the screw mounts on the cabinet. 2. Connect a grounding cable assembly (71073) to one of the screw mounts. 3. Secure the assembly with the two nuts provided. Repeat this procedure for each CHS-4 in the cabinet. Installation—Installing the FC-2000...
  • Page 20 3. Secure the assembly with the two nuts provided. Repeat this procedure for each CHS-4L in the cabinet. U se C a b le 7 1 0 7 3 chsmnt Figure 13: Installing the CHS-4L Chassis 20 Installation—Installing the FC-2000...

  • Page 21: Installing The Avps-24

    Install the AVPS-24 over the screw mounts on the CHS-4 or CHS-4L and Installing the secure with two nuts. Refer to Figure 14. AVPS-24 CHS-4 Chassis AVPS-24 Power Supply CAB-x3 Backbox avpsmnt Figure 14: Installing the AVPS-24 Installation—Installing the FC-2000...

  • Page 22: Mounting The Main Power Supply In The Cabinet

    Place the MPS-24A into the bottom of the cabinet, provided. ensuring that the upper bracket engages the support bracket on the CAB-x3 cabinet. mpsmount Figure 15: Mounting the Main Power Supply in the CAB-x3 22 Installation—Installing the FC-2000...

  • Page 23: Mounting The Arm-4 Auxiliary Relay Module

    4. Complete the installation of the ARM-4 by connecting one end of the ARM-4 ribbon cable to plug P1 on the ARM-4. Connect the other end of the cable to jumper JP5 on the CRM-4 or CRE-4 employed to drive the ARM-4. Installation—Installing the FC-2000...
  • Page 24 All manuals and user guides at all-guides.com Step 1 Step 2 Step 3 Step 4 Existing Standoffs step4arm Figure 16: Mounting the ARM-4 Auxiliary Relay Module 24 Installation—Installing the FC-2000...
  • Page 25 First Row Ribbon Cable 71087 1st Row CPU-2000 (side view) 2nd Row 3rd Row 4th Row E xpand er R ow R ib bon C able 71088 1cpu5000 Figure 17: Connecting Row Ribbon Cables to the CPU-2000 Installation—Installing the FC-2000...

  • Page 26: Mounting Optional Module Expanders

    5. Install the four screws removed earlier through the back of the expander board and into the standoffs. Step 2 Step 1 Module Module Step 4 Step 5 Module Expander M odule Expander Board Board step5ex Figure 18: Mounting Optional Module Expanders 26 Installation—Installing the FC-2000...

  • Page 27: Mounting Modules In The Chassis

    Figure 19. Modules in the Chassis 2. Push the upper end of the module into the chassis and secure with two module screws. Step 1 Chassis Step 2 step2chs Figure 19: Mounting Modules in the Chassis Installation—Installing the FC-2000...

  • Page 28: Mounting The Cpu-2000

    3. Align the module screws with the thread-holes on the chassis and secure in place. Step 1 Step 2 Step 3 CHS-4 Chassis step3cpu Figure 20: Mounting the CPU-2000 28 Installation—Installing the FC-2000...

  • Page 29: Connecting Row Ribbon Cables To Modules

    SW I T CH SW I T CH SW I T CH SW I T CH S W I T C H SW I T CH SW I T CH rowribbn Figure 21: Connecting Row Ribbon Cables to Modules Installation—Installing the FC-2000...
  • Page 30 All manuals and user guides at all-guides.com 30 Installation—Installing the FC-2000...

  • Page 31: Field Wiring The Modules

    1 2 5 V A C 20A 10A 3 0 V D C 20A 10A C o n ta ct R a tin g s arm4mod2 Figure 22: Terminal Assignments for Module Control of the ARM-4 Auxiliary Relay Module Installation—Installing the FC-2000...

  • Page 32: Field Wiring The Cpu-2000

    3. Terminal blocks will accept 12 to 22 AWG wire. 4. Size indicating appliance circuit wire for a maximum drop of 2.0 volts 5. See the Device Compatibility document in the Fire Management Accessories Manual (FAN 445) for compatible indicating appliances. 32 Installation—Installing the FC-2000...

  • Page 33: Dummy-Loading Unused Cpu-2000 Circuits

    B + A + A- B - B + A + A- B + A + A- B - B + A + A- 3 4 5 6 7 8 1 2 3 4 5 6 7 17 18 19 20 dum-load Figure 24: Dummy-Loading Unused CPU-2000 Circuits Installation—Installing the FC-2000...

  • Page 34: Connecting The Rs-485 Interface

    TB1. Note: Twisted shielded cable is required. R S - 4 8 5 Terminal shield of the twisted shielded pair to the entrance point of the cabinet. eia-485 Figure 25: Connecting the RS-485 Interface 34 Installation—Installing the FC-2000...

  • Page 35: Typical Nfpa Style B Initiating Device Circuit

    Connect N.O. waterflow supervisory devices to a dedicated zone programmed for supervisory operation. Terminal Block will accept 12 to 22 AWG wire. Initiating circuit current will ensure alarming of one 2-wire detector only. Installation—Installing the FC-2000...
  • Page 36 24 VDC power, refer to the Applications section of this document. 4. Wire initiating devices according to the manufacturer’s instructions packaged with each device. 5. For Canada, model N-ELR End-of-Line Resistor Assembly required. 6. Maximum line resistance due to wiring is 100 ohms. 36 Installation—Installing the FC-2000...

  • Page 37: Typical Nfpa Style D Initiating Device Circuit

    Connect waterflow alarm devices to a dedicated circuit, programmed for waterflow option. Connect N.O. waterflow supervisory devices to a dedicated zone programmed for supervisory operation. Terminal block will accept 12 to 22 AWG wire. Initiating circuit current will ensure alarming of one 2-wire detector only. Installation—Installing the FC-2000...
  • Page 38 24 VDC power, refer to the Applications section of this document. 4. Wire initiating devices according to the manufacturer’s instructions packaged with each device. 5. Maximum line resistance due to wiring is 100 ohms. 38 Installation—Installing the FC-2000...

  • Page 39: Typical Nfpa Style Y And Z Indicating Appliance Circuit

    1. Indicating appliance circuits are supervised, power limited, and may be connected to energy-limited cable. 2. Use only the compatible, UL Listed indicating appliances listed in Device Compatibility document in the Fire Management Accessories Manual (FAN 445). Installation—Installing the FC-2000...

  • Page 40: Expander (Cre-4)

    Y E LLO W - TR O U BL E O N / O F F O N / O F F Typical Form-C Control crmcrewr Relay in Standby Position Figure 29: Field Wiring of the Control Relay Module (CRM-4) and Control Relay Expander (CRE-4) 40 Installation—Installing the FC-2000...

  • Page 41: Power Supplies

    No more than 6 amps @ 24 VDC can be drawn from the MPS-24A during alarm. Figures 31 and 32 illustrate connections for primary and secondary power to the MPS-24A Main Power Supply, as well as terminal and harness connections for the system. Installation—Installing the FC-2000...
  • Page 42 Power (24 VDC) output or the indicating appliance power output. Both outputs provide the filtered, regulated, power-limited source required by the annunciators. The power run to the annunciators is supervised by the annunciator (loss of communications error). 42 Installation—Installing the FC-2000...
  • Page 43 Power-limited, filtered, regulated, non-resettable, 3 amps (in alarm) max. Battery + Power is supervised by output modules (such as an ICM-4) in the FC-2000. Can also be used to power ACM annunciators. Primary Power 120 VAC, 50/60 Hz, 1.8 amps max.
  • Page 44 C o n ne ct to P 2 o r P 4 . 1 2 3 4 5 6 R 27 T B 2 T B 3 JP 5 M P S - 2 4 A mps24awr Figure 32: Harness Connections for the MPS-24A 44 Installation—Installing the FC-2000...

  • Page 45: Installing An Optional Main Power Meter

    Place the MPM-2 assembly over the standoffs and secure with the two original screws 3. Complete the installation of the MPM-2 by plugging the female connector on the meter cable into plug P7 on the MPS-24A. Installation—Installing the FC-2000...
  • Page 46 M P S -2 4 A Step 2 M P M -2 M P S -2 4 A Step 3 M P M -2 M P S -2 4 A mpminstl Figure 33: Installing an Optional Main Power Meter 46 Installation—Installing the FC-2000...

  • Page 47: Mps-24B Main Power Supply

    ACM annunciators. The power run to the annunciators is inherently supervised (loss of communications error). Note: The total current draw for all annunciator modules and 4-wire detectors cannot exceed 200 mA either in standby or in alarm. Installation—Installing the FC-2000...
  • Page 48 + 5 V D C w h e n M P S -2 4 B e n ters a trou b le c o nd itio n .) Figure 34: Field Wiring the MPS-24B Power Supply 48 Installation—Installing the FC-2000...
  • Page 49 Blue Wire (+) Black Wire (-) Note position of red wire at 8-position end. Power Ribbon Power Harness (71085) (71086) Connect to P2. M P S -2 4 B mps24bwr Figure 35: Harness Connections for the MPS-24B Installation—Installing the FC-2000...
  • Page 50 MPS-24B: TB1-3 (Neutral) and TB1-4 (Hot) First AVPS-24 Last Device in Chain For Multiple Audio Visual Power Supplies Connect to P5 on the MPS-24A, Cables 71033 or to P4 on the MPS-24B. avpswire Figure 36: Field Wiring the Optional AVPS-24 50 Installation—Installing the FC-2000...
  • Page 51 Leave the main power breaker off until installation of the entire system is complete. Connecting the Secondary Power Source (24 VDC) Do not connect AC power or batteries until the system is completely wired and ready for testing. Installation—Installing the FC-2000...
  • Page 52 GC12550 12 VDC 12 VDC NR45-24 55-AH 55-AH Battery Battery Cut JP1 to disable on-board charger M PS-24B T B1 T B2 nr4524 Cut JP2 to diable on-board charger. Figure 37: NR45-24 Remote Battery Charger Connections 52 Installation—Installing the FC-2000...

  • Page 53: Applications

    Maximum Rated Current: 10 mA A supervisory remote station output signal can be obtained by connecting two relay outputs from a Control Relay Module (CRM-4) as shown in Figure 38. The supervisory zone must be programmed to activate both relays. Installation—Installing the FC-2000...

  • Page 54: Central Station

    3. The transmitters are installed according to their instructions in the NIB-96 Network Interface Board Technical Bulletin in the Fire Management Accessories Manual (FAN 445). 4. The controller, transmitters, and receivers must have a standby power source that can supply 24 hours of operating power. 54 Installation—Installing the FC-2000...

  • Page 55: Digital Communicators

    4. The communicator cabinet is installed in the control panel cabinet with all interconnecting wiring installed according to the 911A manual. 5. The controller, communicator, and receiver have a secondary power source that can supply 24 hours of operating power. Installation—Installing the FC-2000...
  • Page 56 Retard time and Reset time must be programmed for zero seconds when connecting the alarm initiating circuit to an existing control panel. For more detailed instructions refer to the 911A Installation Manual. Note: The 911A is not FM-approved. 56 Installation—Installing the FC-2000...
  • Page 57 J P 1 conn911a MPS-24A Figure 40: Connection of a 911A Digital Communicator Note: For supervisory contacts, program the initiating zone(s) and map the output to the supervisory contacts. Set zone 2/3 in DACT for Mode 3. Installation—Installing the FC-2000...

  • Page 58: Tee-Tapping

    T e e -T ap p e d In d ica tin g Style Y A p p lia n ce C ircu it Listed 10K ELR Part No. 71274 teetapp Figure 41: Tee-Tapping Indicating Appliance Circuits Note: Factory Mutual (FM) recommends that this application not be used. 58 Installation—Installing the FC-2000...

  • Page 59: 4-Wire Smoke Detectors

    Common 4-Wire Detector Power -0 VDC UL Listed UL Listed 24 VDC MPS-24A Power Supervision 4-Wire Smoke Detectors TB3 Term 1(+), 2(-) Relay MPS-24B TB2 Term 1(+), 2(-) wire-d Figure 42: Employing 4-Wire Smoke Detectors (Style D) Installation—Installing the FC-2000...

  • Page 60: Indicating Appliance Circuit Current Limitations

    Circuit Current Limitations Note: The term “total” in these figures assumes that no indicating appliance power is drawn for any other purpose. J 5 J 6 ICM-4 ICE-4 botmicm4 Figure 44: Bottom Wire of the ICM-4/ICE-4 60 Installation—Installing the FC-2000...
  • Page 61 T h e se fou r in d icatin g ap p lia n ce circuits sh are th e ICM-4 to tal 3 am ps of curre nt on the A V P S -24 . circonfg Figure 45: Typical Supply/Indicating Appliance Circuit Configurations Installation—Installing the FC-2000...
  • Page 62 A V P S -2 4 sup p lie s to po w e r an IC M -4 or IC E -4), cut jum per JP 1 locate d a bo ve J5 a nd J6. circong2 Figure 46: More Typical Supply/Indicating Appliance Circuit Configurations 62 Installation—Installing the FC-2000...

  • Page 63: Remote Command Inputs

    CPU will deactivate the All Call Telephone Page function (re-execute all zone-to-output mapping). Indicating appliance circuits that should not activate during All Call telephone page must be programmed for non-silenceable and/or switch inhibit operation. Installation—Installing the FC-2000...
  • Page 64 IZM-8 Zone 5: Program zone as non-alarm and supervisory. Use as an evacuation signal for tornadoes, bomb-scares and other non-fire emergency situations. If the FC-2000 is not in alarm, activation (short) on Zone 5 will activate all indicating appliance circuits and output relays mapped to Zone 5 with a steady signal.

  • Page 65: Remote Presignal Inhibit, All Call (General Alarm), Emergency Alert, Acknowledge

    Reset Switches The Presignal Inhibit, Emergency Alert, Acknowledge, Signal Silence, or System Reset functions can be controlled by a relay contact from a CRM-4/CRE-4 Relay Module, which can be operated from switches on ACM-16AT, AEM-16AT, or LDM-32 annunciators. Installation—Installing the FC-2000...
  • Page 66 S ig n a l S ile n c e (S tan d a rd Zo n e ) Sytem Reset Figure 49: Connection Diagram For Remote Presignal Inhibit, All Call (General Alarm), Emergency Alert, Acknowledge, Signal Silence and System Reset Switches (Style B) 66 Installation—Installing the FC-2000...
  • Page 67 (Sta n d a rd Z o ne ) S y te m R es e t izmswch2 Figure 50: Connection Diagram For Remote Presignal Inhibit, All Call (General Alarm), Emergency Alert, Acknowledge, Signal Silence and System Reset Switches (Style D) Installation—Installing the FC-2000...

  • Page 68: Telephone Paging

    RPJ-1 phone jack and begin paging. When paging is complete, remove the handset, wait for speaker activation, lock the RPJ-1, and remove the key. When Zone 2 returns to normal, the CPU will deactivate the telephone circuit and transmit a page-off command to the AMG-1. 68 Installation—Installing the FC-2000...
  • Page 69 RED - CALL LAMPS LAMPS LAMPS LAMPS YELLOW - TROUBLE YELLOW - TROUBLE YELLOW - TROUBLE YELLOW - TROUBLE SWITCH SWITCH SWITCH SWITCH DISPLAY PROGRAM DISPLAY PROGRAM ON/OFF ON/OFF conntele IZM-8 VCM-4 Figure 52: Connection Diagram for Telephone Page Installation—Installing the FC-2000...
  • Page 70 All manuals and user guides at all-guides.com 70 Installation—Installing the FC-2000...

  • Page 71: Testing The System

    When necessary, activation of alarm indicating appliances and speakers can be prevented by depressing the ON/OFF switch on the indicating appliance circuit(s) or speaker circuit(s) to be disabled, while depressing the DISABLE/ENABLE switch. Installation—Installing the FC-2000...
  • Page 72 DISABLE/ENABLE switch on the CPU, followed by depressing the ON/OFF switch on the disabled circuit. 10. Check that all yellow LEDs are off and that the green “AC POWER” LED is illuminated. 11. Notify fire, central station and/or building personnel that test is complete. 72 Installation—Installing the FC-2000...

  • Page 73: Battery Checks And Maintenance

    Accidental shorting of the leads from uninsulated work benches, tools, bracelets, rings, and coins should be avoided. Shorting the battery leads can damage the battery, equipment, and could cause injury to personnel. Installation—Installing the FC-2000...
  • Page 74 All manuals and user guides at all-guides.com 74 Installation—Installing the FC-2000...

  • Page 75: Calculating Power Supply Requirements

    Standby (non-alarm) conditions. Use Table 2 to determine the Standby Load on the MPS regulator. Additional current must be provided by the power supply during an alarm condition. Use Table 2 to determine the current needed in Alarm. Installation—Installing the FC-2000...
  • Page 76 Driver Modules Technical Bulletin in the Fire Management Accessories Manual (FAN 445) Annunciator Modules (Additional LED current for Annunciator LEDs illuminated during non-alarm conditions) ACM-16, 0.016 ACM-32, AEM-16AT, AEM-32A NIB-96 0.022 Continued on next page . . . 76 Installation—Installing the FC-2000...
  • Page 77 ICE-4, CRE-4 0.065 TCM-2, TCM-4 0.072 0.040 VCM-4, VCE-4 DCM-4 0.080 AIM-200 Use alarm total from the AIM-200 Addressable Intelligent Module Technical Bulletin in this manual. Voice Equipment AMG-1/E, 0.095 ATG-2 Continued on next page . . . Installation—Installing the FC-2000...
  • Page 78 External Circuits Draw (refer to Notes 1 and 2): (Alarm 4-Wire Smoke Detectors Draw) Power Supervision Relays Remote 0.018 Station Circuit TCM-2/TCM-4 Circuits Releasing Device Draw Indicating (Alarm Appliances Draw) 911A 0.030 Sum Column for Alarm State Regulator = amps 78 Installation—Installing the FC-2000...
  • Page 79 MPS-24A 0.104 0.064 MPS-24B 0.022 0.062 AVPS-24 0.009 AA-30 0.045 AA-120 0.050 0.011 EFB-1 MPM-2 0.006 IZM-8 0.047 IZE-A 0.004 0.007 ICM-4, CRM-4 ICE-4, VCE-4 0.001 TCM-2, TCM-4, 0.007 VCM-4 Continued on next page . . . Installation—Installing the FC-2000...
  • Page 80 Table 5 assumes that while in alarm, the batteries must feed the MPS-24A/MPS-24B, and any additional supplies (AVPS-24 and AA-30), with the maximum rated power each supply can provide. 80 Installation—Installing the FC-2000...
  • Page 81 2. If the total exceeds 25 AH (17 AH on the MPS-24B), an NR45-24 Remote Battery Charger is needed. If the total exceeds 55 AH, a UL Listed Uninterruptable Power Supply with sufficient amp hour capacity is needed. Installation—Installing the FC-2000...
  • Page 82 9 amps or less JC12250 23-55 AH 9-20 amps GC12550 56 or more AH 21 amps or more UPS required UPS required Battery Charger Amp Hour Range MPS-24A: (9-25 AH) MPS-24B: (6.5-17 AH) NR45-24: (20-55 AH) 82 Installation—Installing the FC-2000...
  • Page 83 All manuals and user guides at all-guides.com Notes Installation—Installing the FC-2000...
  • Page 84 All manuals and user guides at all-guides.com Notes Controls Group FAN 406 507 E. Michigan Street FC-2000 Technical Manual P.O. Box 423 Rev. Level — Milwaukee, WI 53201 Printed in U.S.A. 84 Installation—Installing the FC-2000...
