- Page 1 Form 090.040-I (MAR 2012) INSTALLATION File: SERVICE MANUAL - Section 90 Replaces: S90-130 I (OCT 2004) Dist: 3, 3a, 3b, 3c RETROFIT CONVERSION TO THE FRICK QUANTUM LX/HD CONTROL ® ™ INSTALLATION INSTRUCTIONS Please check www.johnsoncontrols.com/frick for the latest version of this publication.
- Page 2 090.040-I (MAR 2012) FRICK QUANTUM LX/HD RETROFIT ® ™ Page 2 INSTALLATION INSTRUCTIONS FRICK QUANTUM LX/HD RETROFIT PANELS ® ™ The QUANTUM LX/HD Control Panels sold under this program are designed to handle standard screw compressor package ™ design. Compressors are to be electric motor driven only. Other drive lines can be accommodated through Frick Engineering.
- Page 3 FRICK QUANTUM LX/HD RETROFIT 090.040-I (MAR 2012) ® ™ INSTALLATION INSTRUCTIONS Page 3 INSTRUCTIONS structural material. DO NOT WELD WITH THE CONTROL PANEL IN PLACE. Welding currents can cause damage to NOTE: Before proceeding, read the instructions for "Proper the electronic components. Refer to the PANEL MOUNTING Installation of Electronic Equipment in an Industrial Envi- HEIGHT diagram below.
- Page 4 090.040-I (MAR 2012) FRICK QUANTUM LX/HD RETROFIT ® ™ Page 4 INSTALLATION INSTRUCTIONS 21. Refer to the panel wiring diagrams in the Maintenance control power supplied from lighting panels that have manual (090.020 M or 090.040 M) and connect the red, other devices tied to them that generate large amounts black, and white wire of the twisted-three wire to the slide of AC line noise.
- Page 5 FRICK QUANTUM LX/HD RETROFIT 090.040-I (MAR 2012) ® ™ INSTALLATION INSTRUCTIONS Page 5 37. POWER SUPPLY CALIBRATION 38. At this point you should have the operating display on the liquid crystal display panel. A. QUANTUM™ LX - Measure the 5 volt DC power at the Quantum™...
- Page 6 090.040-I (MAR 2012) FRICK QUANTUM LX/HD RETROFIT ® ™ Page 6 INSTALLATION INSTRUCTIONS TRANSDUCER CONNECTION DIAGRAM FOR CONVERTING RWB II TO QUANTUM HD CONTROL ™ QUANTUM™ LX/HD PANEL TRANSDUCER CONNECTION DIAGRAM FOR CONVERTING RWB AND OTHER MANUFACTURER'S UNITS TO QUANTUM HD CONTROL ™...
-
Page 7: Wire Sizing
FRICK QUANTUM LX/HD RETROFIT 090.040-I (MAR 2012) ® ™ INSTALLATION INSTRUCTIONS Page 7 PROPER INSTALLATION OF ELECTRONIC EQUIPMENT IN AN INDUSTRIAL ENVIRONMENT In today’s refrigeration plants, electronic controls have tors, and solenoids. These sudden dips in voltage can cause found their way into almost every aspect of refrigeration the electronic control panel, whether it is a microprocessor, control. - Page 8 The NEC states that will provide better transfer of this noise. control equipment may be grounded by using the rigid conduit Johnson Controls-Frick requires that the ground conductor as a conductor. This worked for the earlier relay systems, but ®...
-
Page 9: Wiring Practices
In addition, dividers must be used for separation of conductors of Johnson Controls-Frick requirements must be followed unlike voltages and types (AC or DC). where they exceed or match national or local codes. - Page 10 090.040-I (MAR 2012) FRICK QUANTUM LX/HD RETROFIT ® ™ Page 10 INSTALLATION INSTRUCTIONS Never run any wires through an electronic control panel device types and proper placement in the panel that will that do not relate to the function of the panel. Electronic keep interference to a minimum.
- Page 11 LX PANELS ™ The use of communications such as serial and ethernet Johnson Controls, Inc. does not advise nor support the use in industrial environments are commonplace. The proper of uninterrupted power supply systems for use with the installation of these networks is as important to the proper Quantum LX panel.
- Page 12 Johnson Controls Supersedes: S90-130 I (2004-10) 100 CV Avenue Subject to change without notice Waynesboro, PA 17268-1206 USA Published in USA • 0812 • GUI 50 Phone: 717-762-2121 • FAX: 717-762-8624 www.johnsoncontrols.com/frick © 2012 Johnson Controls Inc. - ALL RIGHTS RESERVED...
