Installing the Mains/Power Filter (Hard wired versions only)

36.1 Place the new mains/power filter (Fig 24, Item 60) in position in the casing, and install the screw
(Fig 24, Item 70) to secure it.
Note: Make sure that the 5 wires from the mains/power filter are routed correctly, and are not trapped
beneath the filter. The ends of the wires should be accessible, and not obscured beneath the 5-
way connector (Fig 24, Item 40).
36.2 Refer to Figure 24 and Table 18, and connect up the 5 wires on the mains/power filter.
Note: The side of the filter with 2 wires (brown and blue) is the "input", and the side with 3 wires
(brown, green/yellow and blue) is the "output".
Note: In Table 18, "Terminal 1" is at the bottom of the 5-way connector (nearest the bottom wall
of the casing).
36.2.1 Tighten the screws in the 5-way connector (Fig 24, Item 40) to secure the wires.
36.2.2 Install the earth wire tag from the mains/power filter onto the earth stud on the right
compressor mounting bracket. Make sure the other earth wire tags are still on the earth
stud (Refer to Figure 24). Then install the top washer (Fig 24, Item 30) and nut
(Fig 24, Item 10), and tighten.
36.3 Cable tie the wires, as necessary.
36.4 Install the bio filter (Refer to Page 59, Section 48)
36.5 Assemble the rear case (Refer to Page 5, Section 5)
.
Table 18 - Mains/Power Filter Connections (Hard wired versions only)
Mains/Power Filter
Input - Brown Wire
Input - Blue Wire
Output - Brown Wire
Output - Blue Wire
Output - Green/Yellow Wire
Issue 2
April 2010
5-Way Connector
Terminal 1 - Left Side
Terminal 2 - Left-Side
Terminal 4 - Left-Side
Terminal 5 - Left-Side
-
SER0001
Pump Repair
Other
-
-
-
-
Earth Stud on Right
Compressor Mounting Bracket
