Disassembling the Pump Filter

6.1 Disassemble the Rear Case (Refer to Chapter 3, Page 5, Section 4).
6.2 Lay the Rear Case on a flat surface and remove the six screws (Fig 5, Item 40) and keep them
in a safe place.
6.3 Remove the Filter Housing Plates (Fig 5, Item 20) and the Filter (Fig 5, Item 30).
6.4 Discard the old Filter.
7

Assembling the Pump Filter

7.1 Assembly of the new Pump Filter is in the reverse order of disassembly. Make sure the slots in
the Filter Housing Plates (Fig 5, Item 20) are uppermost in the positions shown in Figure 5.
7.2 Assemble the Rear Case (Refer to Chapter 3, Page 5, Section 5).
Item Part Number
10 151308
20 151311
30 151312
40 FAS179
Issue 2
April 2010
Table 4 - Pump Filter Parts List
Rear Case
Filter Housing Plate
Filter
Pan Hd Self Tapping Screw (Dia 2.5mm x 10 mm)
SER0001
Description
Pump Repair
Qty
1
2
1
6
