Getinge Arjohuntleigh NIMBUS II Service Manual page 29

Nimbus/DFS Service Manual
.
Item Part Number
10 165076
- 165074
- 165077
- 165078
20 165311
30 165312
40 165300
45 165303
50 FAS177
60 FAS144
70 FAS053
80 FAS093
90 FAS053
100 FAS160
110 151386
120 FAS095
130 151310
140 FAS178
150 FAS160
160 FAS053
170 151364
Issue 2
April 2010
Table 5 - Compressor Parts List
Double Compressor Assembly - 220V (UK, EURO)
Double Compressor Assembly - 120V (USA)
Double Compressor Assembly - 100V (Japan 60Hz)
Double Compressor Assembly - 100V (Japan 50Hz)
Compressor Lid
Compressor Lid Gasket
Grommet Blank
Grommet Blank - Lead through
Screw M4 8mm Torx C'SK Head
Nut M4 Full
Washer M4 Anti-Vib
Screw M4 12mm
Washer M4 Anti-Vib
Washer M4 Plain
'P' Clip No.6
Screw M4 10mm Pan Head Pozi
Compressor Mounting Bracket
Nut 8/32 UNC
Washer M4 Plain
Washer M4 Anti-Vib
AV Mount
SER0001
Description
Pump Repair
Qty
1
1
1
1
2
2
4
4
8
2
2
2
2
2
3
4
2
8
6
2
4
Chap 3
Page 11
