- Page 1 Typhoon Assembly and Installation Instructions ...with people in mind 6001269102_EN Rev F • 02/2018...
- Page 2 The model name and serial number should always be provided when ordering spare parts or during queries per telephone or written correspondence: Serial number of the machine: …………………………………………………… Machine model: …………………………………………………… Design Policy and Copyright ® and ™ are trademarks belonging to the ArjoHuntleigh group of companies. © ArjoHuntleigh 2017. As our policy is one of continuous improvement, we reserve the right to modify designs without prior notice.
-
Page 3: Table Of Contents
Contents PREFACE ..........................4 1 SAFETY PRECAUTIONS ....................5 1.1 Important ......................6 1.2 Make sure assembly and installation work is carried out by ........7 1.3 Isolator switch ......................7 1.4 In an emergency ....................7 1.5 Product liability .....................7 1.6 Attention symbols ....................7 2 INSTALLATION ......................8 2.1 General ........................8 2.1.1 Make sure assembly and installation work is carried out ......8 2.1.2 Installation order ...................8... -
Page 4: Preface
PREFACE The user manual describes the design and operation of the machine and the maintenance for which the user is responsible. The installation manual describes the machine’s installation. The technical manual describes necessary information for operators and maintenance personnel. The information in the manual must be complied with to ensure safe and error-free operation. -
Page 5: Safety Precautions
1 SAFETY PRECAUTIONS This machine has a number of built-in safety devices. To avoid injury, it is highly important not to bypass these safety devices. If the equipment is used in a manner not specifi ed by the manufacturer this can impair the safety equipment on the machine. Operators and maintenance personnel must undergo safety training for the machine. -
Page 6: Important
1.1 Important • Take care when handling the chemical agents used in the machine. Read the details on the container or contact the manufacturer: ͦ if the agent comes into contact with the operator’s eyes or skin or if the vapors are breathed in, etc. ͦ... -
Page 7: Make Sure Assembly And Installation Work Is Carried Out By
1.2 Make sure assembly and installation work is carried out by • by qualifi ed personnel. • in accordance with current local regulations and rules. 1.3 Isolator switch The machine must always be equipped with a separate isolator switch in the feed power supply. The isolator switch must be easily accessible on a wall close to the machine. -
Page 8: Installation
2 INSTALLATION 2.1 General 2.1.1 Make sure assembly and installation work is carried out To avoid the risk of back injury, this equipment should be assembled and installed by at least two people. • by qualifi ed personnel. • in accordance with current local regulations and rules. •... -
Page 9: Unpacking
2.2 Unpacking Note! Before installing make sure the fl usher-disinfector has not been damaged in transit. The following items must accompany the fl usher-disinfector when it is delivered: • Two cabinet keys • One folder containing documentation The fl usher-disinfector is supplied securely bolted to a pallet. Remove the packaging. -
Page 10: Diagram Showing Dimensions And Hole Pattern
2.3 Diagram showing dimensions and hole pattern 14(2X) 12(2X) 10(2X) 80-320 120-330 Figure 2. Diagrams showing dimensions and hole pattern 1. CW, G1/2" female (TWO METERS OF 3. WASTE CONNECTION, P-TRAP, WALL, HOSE FROM THIS POINT ARE INCLUDED 110/90. WITH THE MACHINE) 4. -
Page 11: Positioning
2.4 Positioning • Fit the trap to the waste outlet. The trap can be connected towards the rear or downwards. The pipe diameter is 90 or 110 mm. • Position the machine and level it using a spirit level held vertically against the side of the machine. - Page 12 Figure 4. Handling panels • Release the panel and lock it in the service position. • Measure up and drill the holes for securing the machine to the wall.
- Page 13 Figure 5. Measure up the holes on the wall • Fix the machine to the wall. Use suitable screws and washers for the material of the wall. Note! When the plinth is removed, the entire weight of the machine is now supported by the bolts in the wall. •...
-
Page 14: Connecting Water
2.5 Connecting water • The connections must satisfy the requirements for water connection in accordance with the table below. Cold water Blue Warm water Red Connection 15 mm (1/2") 15 mm (1/2") Pressure 100-800 kPa 100-800 kPa Flow rate 20 l/min at 400 kPa 20 l/min at 400 kPa pressure pressure... -
Page 15: Coupling Alternative
2.6.1 Coupling alternative 3N+PE 1N+PE -X50 -X50 Figure 8. Electrical connection 3+PE 2+PE -X50 -X50 Figure 9. Electrical connection Voltage Connection Frequency Fuse Power requirement 400 V 3N+PE (TN) 60 Hz 3 × 15 A 5.71 kW 400 V 3N+PE (TN) 50 Hz 3 ×... -
Page 16: When The Work Is Complete, Check That
2.7 When the work is complete, check that • all parts have been installed according to the installation manual. • all screws have been properly tightened. • there are no sharp edges on any parts that may come into contact with people. •... -
Page 17: Function Check
2.8 Function check Note! Make sure that the suction hose in the dosing pump is full of agent before beginning. The dosing pumps can be operated separately in the service program to fi ll the hoses with agent, line 82 (se Technical manual). •... - Page 18 Figure 10. Control panel 1. Yellow: Process running 2. Green: Process complete 3. Red: Disinfection not achieved or other error code F 4. Display 5. Rim fl ushing 6. Option (detergent) 7. Open/close door. 8. Sensor to open/close door and to start preselected program 9.
-
Page 19: Technical Data
3 TECHNICAL DATA 3.1 Dimensions and weights Dimensions and weights Weight 135 kg Width 600 mm Depth 600 mm Height (incl. plinth 200 mm) 1840 mm... -
Page 20: Connections
3.2 Connections Water consumption Economy program 25 ± 10% l/process Normal program 31 ± 10% l/process Intensive program 39 ± 10% l/process Cold Water Connection 15 (1/2") mm Pressure 100-800 kPa Flow rate 20 l/min Hot Water Temperature 45-60°C (113 - 140°F) Connection 15 (1/2") mm Pressure... -
Page 21: Miscellaneous
3.3 Miscellaneous Miscellaneous Dead volume <2.3 l (main pump and steam generator) Sound level 60 dB (A) leq 3.4 Environmental requirements Air humidity, maximum 80% at 31°C (87°F) Room temperature 5 - 40°C (41 - 104°F) 3.5 Protection class Pollution Degree Overvoltage category Protection class IP 21... -
Page 22: Accessories
3.6 Accessories Article number Description 499631900 Combination valve (shutoff valve/ non-return valve/fi lter) 1 pair 502321001 Isolator switch JAA101090 Tray for instruments JAA101490 Insert tray 502391600 P-trap, (diam. 110 mm) 502391700 S-trap, (diam. 110 mm) 502391800 P trap (diam 90 mm) 502391900 S trap (diam 90 mm) 502520100... -
Page 23: Water Quality
4 WATER QUALITY It is the customer’s responsibility to supply the washer-disinfector with water of the right quality. The quality of the water used in all stages of cleaning is important for good cleaning results. The water used in each step should be compatible with: •... - Page 24 ArjoHuntleigh AB recommends that water used in the pre-rinsing, washing and fi nal rinsing phases should be of drinking quality in accordance with the guidelines. Recommended water quality is drinking water with max 5°dH. Detailed information about acceptable water quality can be found in “Guidelines for Drinking Water Quality, published by WHO.
-
Page 25: Handling Of Worn Products
5 HANDLING OF WORN PRODUCTS This product and its accessories comply with the requirements in the WEEE directive (Waste Electrical & Electronic Equipment) 2012/19/EU. Worn-out products must be disposed of at recycling stations in accordance with local regulations. If required, contact your reseller for more information. - Page 26 Intentionally left blank...
- Page 27 Fax: + 61 89337 9077 E-mail: info.france@arjohuntleigh.com PORTUGAL BELGIQUE / BELGIË HONG KONG ArjoHuntleigh em Portugal ArjoHuntleigh NV/SA Getinge Group Hong Kong Ltd MAQUET Portugal, Lda. Evenbroekveld 16 1510-17, 15/F, Tower 2 (Distribudor Exclusivo) BE-9420 ERPE-MERE Kowloon Commerce Centre Rua Poeta Bocage n.º 2 - 2G Tél/Tel: +32 (0) 53 60 73 80...
- Page 28 ArjoHuntleigh AB Hans Michelsensgatan 10 211 20 Malmö, Sweden www.arjohuntleigh.com ArjoHuntleigh is a world-leading provider of integrated products and solutions that improve the lives of patients and residents with reduced mobility. We help healthcare facilities deliver wellness and effective everyday care, early mobilisation, safe patient handling, venous thromboembolism prevention, pressure injury prevention, hygiene routines, bariatric care and diagnostics.
